Part of the New Holland Repair Manuals.
This is the full factory service manual for the New Holland TN75FA, TN85FA and TN95FA tractors, the narrow orchard and vineyard models, the same workshop information a dealer technician works from. It covers the whole tractor: the diesel engine (rated 74 HP on the TN75FA, 84 HP on the TN85FA and 92 HP on the TN95FA), the clutch, the transmissions, the drive lines and four-wheel drive front axle, the rear axle and final drive, the power take-off, the brakes, the hydraulic systems and hitch, the steering, the axles and wheels, the cab air conditioning, the full electrical system with the wiring diagrams and the platform, cab and bodywork. Every section carries the specifications and capacities, the tightening torques, the functional adjustments, the fault finding and the step-by-step removal, overhaul and installation procedures, so you can chase an engine, transmission or hydraulic problem and put it right instead of guessing.
What's Inside This New Holland New Holland TN75FA TN85FA TN95FA Manual
| System | Pages | Key Topics |
|---|---|---|
| General Guidelines and Specifications | General Service Instructions, Safety Precautions, Machine Specifications and Capacities, Standard Tightening Torques, Special Tools, Model Coverage TN75FA TN85FA TN95FA | |
| Engine | Diesel Engine Description and Operation, Rated Power 74/84/92 Hp, Cylinder Head and Valves, Pistons and Connecting Rods, Crankshaft and Timing, Cooling and Lubrication, Fuel Injection, Engine Removal and Overhaul | |
| Clutch | Clutch Assembly Description and Operation, Clutch Release Mechanism, Pedal Free Play and Adjustment, Clutch Removal, Inspection and Overhaul, Fault Diagnosis | |
| Transmissions | Gearbox and Range Transmission, Synchroniser and Shuttle, Gear Selection and Linkage, Transmission Oil Flow, Description and Operation, Fault Diagnosis, Overhaul | |
| Drive Lines and Four-Wheel Drive Front Axle | Drive Lines and Propeller Shafts, Four-Wheel Drive Front Axle, Front Differential and Bevel Gears, Planetary Wheel Hubs, Axle Shafts, Engagement, Fault Diagnosis, Overhaul | |
| Rear Axle and Final Drive | Rear Mechanical Transmission, Differential and Differential Lock, Final Drive and Bull Gears, Rear Hubs, Description and Operation, Fault Diagnosis, Overhaul | |
| Power Take-Off | Power Take-Off Clutch and Shaft, Rear and Ground-Speed PTO, Engagement and Interlock, Adjustment, Fault Diagnosis, Overhaul | |
| Brakes | Service Brakes and Parking Brake, Brake Discs and Actuators, Hydraulic Brake Control Circuit, Pedal Adjustment and Bleeding, Description, Fault Diagnosis, Overhaul | |
| Hydraulic Systems | Hydraulic Pump and Circuits, Rear Lift and Three-Point Hitch, Remote Valves, Draft and Position Control, Pressure Testing, Fault Diagnosis, Overhaul | |
| Steering, Axles and Wheels | Hydrostatic Power Steering, Steering Cylinder and Pump, Front Axle Beam, Front and Rear Wheels and Tyres, Toe-In and Track Setting, Description, Fault Diagnosis, Overhaul | |
| Electrical System | Wiring Diagrams, Starting and Charging Systems, Battery, Alternator and Starter Motor, Lighting, Instruments and Warning Devices, Switches and Sensors, Fault Diagnosis | |
| Cab, Air Conditioning and Bodywork | Operator Cab and Platform, Air Conditioning and Heating, Compressor and Refrigerant Circuit, Controls and Instruments, Doors, Glass and Trim, Bodywork Panels, Service |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| TN75FA | ||
| Rated Power - TN75FA | 54.5 kW (74 HP) | |
| TN85FA | ||
| Rated Power - TN85FA | 61.5 kW (84 HP) | |
| TN95FA | ||
| Rated Power - TN95FA | 67.5 kW (92 HP) | |
| All models | ||
| Configuration | Narrow orchard and vineyard tractor | |
| Drive | Two-wheel drive or four-wheel drive | |
New Holland New Holland TN75FA TN85FA TN95FA Common Problems This Manual Covers
Three-point hitch lifts slowly, will not hold, or drops under load.
Work the Hydraulic Systems section: it covers the pump output, the lift control valve and the draft and position control and gives the pressure-testing procedure to find whether the pump, a control valve or worn lift cylinder seals are behind the slow or dropping hitch.
Manual Section: Hydraulic SystemsCab air conditioning cuts out or will not cool.
Work the Cab, Air Conditioning and Bodywork section: it covers the compressor, the refrigerant circuit and the controls and gives the checks and the diagnosis to find the leak, the failed compressor or the control fault behind an A/C that will not cool.
Manual Section: Cab, Air Conditioning and BodyworkFour-wheel drive will not engage or the front axle is noisy.
Work the Drive Lines and Four-Wheel Drive Front Axle section: it covers the drive lines, the front differential and the planetary hubs and gives the engagement checks, fault diagnosis and overhaul to restore drive and cure front-axle noise.
Manual Section: Drive Lines and Four-Wheel Drive Front AxleEngine is hard to start, smokes, or lacks power.
Work the Engine section: it covers the fuel injection, the compression and the valve and timing and gives the specifications, the diagnosis and the overhaul to cure hard starting, smoke and low power on the TN-FA diesel engine.
Manual Section: EngineFrequently Asked Questions
Does the manual give the engine specifications and overhaul for the TN-FA tractors?
Yes. The Engine section covers the diesel engine rated at 74 HP on the TN75FA, 84 HP on the TN85FA and 92 HP on the TN95FA, with the cylinder head, pistons, crankshaft and timing, the specifications and torques and the full overhaul.
The three-point hitch or hydraulics lift slowly or not at all - what does the manual cover?
The Hydraulic Systems section covers the pump and circuits, the rear lift and three-point hitch, the remote valves and the draft and position control, with the pressure testing and fault diagnosis to fix a slow or weak lift.
The cab air conditioning has stopped cooling - is that covered?
Yes. The Cab, Air Conditioning and Bodywork section covers the compressor and refrigerant circuit, the controls and the diagnosis so you can find why the orchard cab has stopped cooling and put it right.
Does this manual include the wiring diagrams and electrical diagnostics?
Yes. The Electrical System section carries the wiring diagrams, the starting and charging systems, the instruments and warning devices and the switches and sensors, so you can trace an electrical fault on the TN75FA, TN85FA or TN95FA.
Which models does this manual cover and what are they?
It covers the New Holland TN75FA, TN85FA and TN95FA - the narrow orchard and vineyard tractors - including the engine, clutch, transmission, four-wheel drive, hydraulics, steering, cab air conditioning and electrical systems.
How will I receive this New Holland TN75FA, TN85FA, TN95FA Service Manual?
You get a 1272-page searchable PDF (37 MB) that downloads instantly after checkout. Open it on your laptop, tablet, or phone, and bring it right to the shop floor.
Can I print specific sections of this New Holland TN75FA, TN85FA, TN95FA manual?
Absolutely. No DRM or copy protection. Print the whole manual or just the pages you need. Any home or office printer works.
Reviews
There are no reviews yet.
