Need the factory operating guide for your Case CVX 1135, 1145, 1155, 1170, or 1195? This 274-page operator manual (OEM #Sva 6-37143) puts every procedure, interval, and specification for those five CVX tractors in one place. Inside: a thorough instruments and controls section walking through display programming, seat adjustment, and every cab control, plus complete driving procedures covering cold-weather starts, transmission operation, and EDC electronic three-point hitch management. You also get a dedicated lubrication and maintenance section with daily inspection checklists, fluid fill levels for every circuit, and service intervals including pressure filter replacement at 500 hours and suction filter at 1000 hours. Fuel injector nozzle opening pressure is 270 +8 bar. Every hour that machine sits is money; pull up the bookmarked PDF on your tablet, find the right spec, and get rolling.
What's Inside This Case CVX1135/CVX1145/CVX1155/CVX1170/CVX1195 Operator Manual
| System | Pages | Key Topics |
|---|---|---|
| To the User | 8-12 | How to Use This Manual, Keeping Your Manual Safe, Declaration of Conformity, Type Approval, Software Status, Airborne Noise Emitted |
| Aggregate/Serial Numbers | 13-14 | Product Identification and Serial Number |
| Safety/Safety Plates | 15-20 | Safety, Correct Usage, Carriage of Passengers, Leaving the Tractor, Attachments, PTO Shaft Operation, Maintenance and Other Work, Dangerous Chemicals |
| Instruments/Operating Controls | 21-73 | Climbing Onto the Tractor, Driver's Seat, Programming the Displays, Operating Controls |
| Driving | 74-123 | Before Starting the Engine, Battery Master Switch, Driving Seat Switch, Starting Procedure, Operating the Tractor at Low Temperatures, Drive Strategies |
| Operational Use | 124-174 | Operating the Case Front PTO Shaft, Preparing the Rear Three-Point Linkage, Operating the Electronic 3-Point Hitch Control, Preparing the Case Front Hitch |
| Tyres/Wheels/Track Width/Ballast | 175-189 | Front Axle and the Front Axle Track Width, Front Axle Track, Rear Axle Track Width, Wheel Drive Tyre Combinations, Front Wheel Mudguard -, 4-Wheel Drive Tractor, Tractor Ballast |
| Lubrication/Maintenance | 190-229 | Lubrication and Filling Levels, Daily Inspections, Engine Maintenance, Engine/transmission Unit Maintenance, Hydraulics Maintenance, Front Axle Maintenance |
| Electrical System | 230-248 | Battery, Replacing Bulbs and Lamps, Fuses and Relays |
| Technical Data | 249-259 | Engine, Vehicleweights, Vehicle Diminsions |
| Reversing Mode | 260-263 | Reversible Seat/Reversing Facility |
| Virtual Terminal Monitor | 264-269 | General Information, Operation, Switches and Vt Display, Control Units and Vt Switching Systems, Vt Screen Page Setting, Use of Memory |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| Pressure filter replacement interval | 500 hours | p. 198 |
| Suction filter replacement interval | 1000 hours | p. 198 |
| Dry filter cartridge replacement interval | at least 1 x year | p. 198 |
| Safety cartridge replacement interval | at least 2 years | p. 199 |
| Nozzle opening pressure | 270 + 8 bar | p. 250 |
| Engine capacity | 6595 cm³ | p. 249 |
| Nominal engine speed | 2100 rpm | p. 249 |
| Engine oil fill level | 20.0 litres | p. 193 |
| Coolant fill quantity | 25 litres | p. 193 |
| Fuel tank capacity | 310 litres | p. 193 |
| Hydraulic system operating pressure | 205 bar | p. 253 |
| Rear axle planetary gear fill quantity (135 HP / 145 HP models) | 10 litres per side | p. 193 |
Case CVX1135/CVX1145/CVX1155/CVX1170/CVX1195 Common Problems This Manual Covers
Case CVX 1135 dashboard shows error E023, transmission oil pressure warning light stays on
Stop the tractor immediately and check the transmission oil level at the sight glass before restarting. Pull up the error code reference for E023 fault details. Confirm filter service history on page 191: the pressure filter must be replaced every 500 hours, the suction filter every 1000 hours. Do not resume heavy work until the oil pressure warning clears.
Manual Section: Instruments/Operating ControlsEngine coolant temperature warning E011 flashes on display during extended PTO or field work
Stop the tractor and idle at low speed for 5 minutes before shutdown — never cut a hot engine. Check the coolant reservoir against the MIN/MAX marks; total capacity is 25 litres (page 193). Clear chaff or crop debris blocking the radiator grille screen. Consult the error code reference for E011 and follow the listed steps before resuming operation.
Manual Section: Instruments/Operating ControlsHydraulic lift arms drop slowly under load or won't hold implement at set working height p. 190
Check hydraulic oil level at the sight glass shown in the maintenance section on page 190. Verify the electronic 3-point hitch control settings match the implement weight class per the operational use section on page 124. The hydraulic system is rated at 205 bar (page 253); if sinking continues, confirm the hydraulic filter replacement schedule on page 191 is current before returning to work.
Manual Section: Operational UseEngine stalls intermittently during field operation with no warning lights or error codes shown
Check fuel level first — the tank holds 310 litres (page 193) and the gauge can lag on slopes. Drain water from the fuel pre-filter bowl into a container and inspect for sediment. Verify the air filter service indicator is clear; the dry filter cartridge must be replaced at least once per year (page 191). Follow the troubleshooting procedures if stalling continues.
Manual Section: Lubrication/MaintenanceBattery warning light on after seasonal storage, tractor cranks slowly or fails to start in cold weather p. 230
Verify the battery master switch is fully engaged per the starting procedure on page 74. Inspect both terminals for corrosion and clean before tightening. The battery is rated at 180 Ah (page 251); a partially discharged unit won't deliver enough cold-cranking current, so charge it fully before the next start attempt. Review the electrical system section starting page 230 for further inspection steps.
Manual Section: Electrical SystemFrequently Asked Questions
How to reset the error code on Case CVX 1135?
To reset an active fault displayed on the ADIC, press the tractor reset key (9) for 5 seconds. This action will suppress the fault display, allowing the driver to continue work, although any associated warning lamps will remain active. This function is only valid when an active fault is present.
How to reset the transmission fault on Case CVX 1155?
An active transmission fault, identified by the FMGR (Vehicle/transmission controller), can be temporarily suppressed from the ADIC display by pressing the tractor reset key (9) for 5 seconds. However, any associated warning lamps will remain active, and it is recommended to consult an authorized dealer for persistent faults.
What are the replacement specifications for Transmission fluid filter?
For transmission fluid filters, if fault code 128 (suction filter) or 136 (pressure filter) appears, replace the respective filter. The pressure filter involves screwing off the bowl, cleaning it, and replacing the paper filter cartridge (3) and o-ring (4).
What are the replacement specifications for Engine air filter?
The engine's safety air filter cartridge should be renewed after performing maintenance on the main cartridge 5 times, or at least every 2 years. It must also be replaced immediately if the maintenance indicator lights up again after cleaning the main cartridge, or if the main cartridge is defective.
Is this Case CVX 1135 & variants Operator Manual a digital download?
A 274-page Operator Manual in searchable PDF format, available the moment you complete checkout. View on computer, tablet, or phone, with no shipping wait.
Am I able to print pages from this manual?
Absolutely. No DRM or copy protection. Print the whole manual or just the pages you need. Any home or office printer works.
