All 111 pages of this Case IH DX35 Operator Manual (OEM #86617827) are written for the DX35, DX40, and DX45 tractors — your factory reference for daily operation and scheduled maintenance on the Case IH d35 operator manual pdf you've been hunting. Open it and you get complete instrument panel walk-throughs, ROPS and seat setup procedures, PTO and brake controls, hydraulic system operation, and a full lubrication and maintenance chapter covering every service interval from pre-start checks to long-term fluid changes. A specs section gives you numbers you can act on: hydraulic pump output is 37.1 lpm (9.8 gpm), system relief valve is set at 160 bar (2275 PSI), and the radiator cap holds 0.9 bar (13 PSI). Your machine is down and forum posts won't fix it. Grab the factory answer. Bookmarked and keyword-searchable — jump straight to the section you need, right from your phone in the field.
What's Inside This Case IH D35–D45 / DX35–DX45 Operator Manual
| System | Pages | Key Topics |
|---|---|---|
| Safety | 7-15 | - |
| General Information | 16-19 | Product Identification, Inch Hardware, Metric Hardware, International Symbols |
| Operation | 20-53 | Seat and ROPS, Instrument Panel, Starting the Engine, Brake Controls, PTO Control, Hydraulic System |
| Lubrication and Mainttenance | 54-95 | - |
| Specifications | 96-105 | Engine and Capacities, Electrical and Fuel Systems, Hydraulic Lift System, Transmission Speeds, Weights and Hitch, Dimensions and Clearances |
| Predelivery Service | 108-111 | Inoperative Service Checks, Operative Service Checks, Safety Items Checks |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| All Models | ||
| Hydraulic Pump Capacity | 37.1 lpm (9.8 U.S. gpm) | p. 98 |
| Radiator Cap Pressure | 0.9 bar (13 PSI) | p. 97 |
| Water Pump Type | Centrifugal | p. 97 |
| Hydraulic System Relief Valve Setting | 160 bar (2275 PSI) | p. 98 |
| Thermostat Start to Open Temperature | 71°C (160°F) | p. 97 |
| Thermostat Fully Open Temperature | 85°C (185°F) | p. 97 |
| Fuel Filter Element Service Interval | 200 hours | p. 55 |
| Fuel Tank Capacity | 13 U.S. gals. | p. 96 |
| Rear Axle & Transmission (Includes Hydraulics) Capacity | 9.6 U.S. gals. | p. 96 |
| DX35 | ||
| Cooling System Capacity | 7.8 U.S. qts. | p. 96 |
| Rear PTO Operation | 27.7 HP | p. 98 |
| DX40, DX45 | ||
| Engine Crankcase Capacity | 6.3 U.S. qts. | p. 96 |
