This is the factory parts catalog for the Kubota B6200D compact diesel tractor, a 198 page PDF you download and keep. It reproduces Kubota's own exploded diagrams and part number tables for the entire machine, covering the crankcase, cylinder head and injection pump, the transmission and rear axle, the hydraulics, steering, front axle and electrical parts.Each assembly pairs a numbered illustration with the matching Kubota part numbers, quantities and serial number ranges, so you can identify the exact component before ordering rather than guessing between parts that look alike but fit a different serial range.Owners of the four wheel drive B6200D rely on catalogs like this to look parts up by diagram, which is far faster than searching by description. Use it to rebuild the engine, chase a steering or hydraulic problem, or replace worn wear items, and print only the pages you need for the job at the bench.
What's Inside This Kubota B6200D Parts Manual
| System | Pages | Key Topics |
|---|---|---|
| Clutch & Transmission | Transmission Case, Clutch Rod, Clutch, 2Nd Shaft, 3Rd Shaft, 4Th Shaft, 5Th Shaft, Reverse Shaft, Speed Change Fork, Main Speed Change, Aux. Speed Change, Rotary Speed Change Fork, Speed Change Lever, Clutch Housing/Step/Starter | |
| Fuel System | Injection Pump, Nozzle Holder, Engine Stop Lever, Speed Control Plate, Governor, Fuel Tank, Fuel Pipe, Fuel Filter, Decompress Wire and Engine Stop Wire, Air Cleaner | |
| Cooling System | Water Flange, Water Pump, Radiator | |
| Engine | Crankcase, Oil Pan, Cylinder Head, Gear Case, Main Bearing Case, Cylinder Head Cover, Valve/Rocker Arm, Camshaft, Piston/Crankshaft, Flywheel, Muffler and Muffler Pipe, Front Gear Case, Horizon Muffler | |
| Electrical System | Dynamo, Battery, Panel Switch, Flasher Light/Tail Light/Head Lamp, Dynamo 1, Dynamo 2, Working Light, Starter | |
| PTO | PTO Cover, PTO Shaft, Flange F.Pto | |
| Rear Axle, Differential & Brakes | Rear Axle Case, Spiral Bevel Shaft, Rear Differential, Rear Axle, Rear Wheel, Rear Wheel Hub, Brake, Brake Rod, Front Axle Case | |
| Front Axle & Steering | Steering, Front Axle Frame, Knuckle Arm, Front Differential, Front Wheel Hub, Front Wheel B6200D-Gp-, B7200D-P, Front Wheel B6200D-P, Front Wheel | |
| Hydraulics & 3-Point Hitch | Hydraulic Pump, Hydraulic Pipe, Hydraulic Block, Hydraulic 2, 3-Point Linkage, Hydraulic Outlet, Control Valve | |
| Body & Operator Station | Case Cover, Seat, Fender, Hood, Panel | |
| Decals & Accessories | Label, Accessories and Service Parts | |
| Other Components | Manifold, Pedal, Release Rod, Drive Shaft |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| Oil PAN weight | 1.1 kgf | p. 10 |
| Rear Wheel tire size | 7-16 | p. 92 |
| Front Wheel tire size | 6-12B | p. 172 |
| Washer,Adjusting thickness | 1.00MM | p. 54 |
| 2ND Shaft Gear teeth | 29T | p. 76 |
| Rear Differential Assy Gear,Bevel ratio | 6-37T | p. 88 |
Kubota B6200D Common Problems This Manual Covers
Steering play or stiff steering
Owners report steering play and stiffness that need new rods, bearings and tubes on the B6200D. The Steering section identifies the box, shaft and linkage parts so you can order the correct replacements.
Manual Section: Steering p. 115Weak or slow hydraulic lift
A worn hydraulic pump leaves the lift slow or unable to hold load. The Hydraulic Pump section breaks down the pump body, gears and seals for a clean rebuild or replacement.
Manual Section: Hydraulic Pump p. 41Hard starting or poor running
Air in the fuel, clogged filters or injector wear cause hard starting on these diesels. The Fuel Filter section identifies the filter, element and related fittings for service.
Manual Section: Fuel Filter p. 147Loss of drive or drivetrain trouble
Loss of motion or abnormal drivetrain behavior can come from low fluid, clutch wear or internal transmission failure. The Transmission Case section shows the case and its internal parts.
Manual Section: Transmission Case p. 61Overheating and cooling parts wear
Cooling faults on older tractors trace to a tired radiator, cap or hoses. The Radiator section identifies the radiator assembly and mounting parts by Kubota part number.
Manual Section: Radiator p. 133Clutch drag or slipping
Worn clutch parts cause dragging, slipping or hard engagement. The Clutch section lays out the disc, cover and release components with their part numbers.
Manual Section: Clutch p. 73Frequently Asked Questions
Which tractor does this catalog cover?
It covers the Kubota B6200D four wheel drive compact diesel tractor. Parts list by Kubota part number with quantities and serial number ranges so you match components to your exact machine.
Does it include torque specs and repair steps?
This is a parts catalog, so it provides exploded diagrams, part numbers and component weights rather than repair procedures or torque tables. Its purpose is identifying and ordering the correct parts.
Where do I find the steering parts?
The Steering section covers the box, shaft, rods and linkage by part number, which is where owners start when replacing worn steering components that cause play or stiffness. p. 115
Can I break down the hydraulic pump for a weak lift?
Yes. The Hydraulic Pump section separates the pump into body, gears, seals and fasteners so you can order exactly what a slow or weak hydraulic lift needs. p. 41
Is this Kubota B6200D Parts Catalog a digital download?
Yes. Instant PDF download. The full 198-page searchable Parts Catalog is available immediately after payment. Works on laptop, tablet, or phone right in the shop.
Is this Kubota B6200D Parts Catalog printable?
Zero restrictions. Print individual pages, full chapters, or the entire catalog. The PDF is completely unlocked.
Are hydraulic system diagrams in this Kubota B6200D Parts Catalog?
This is a parts catalog with exploded parts diagrams and OEM part numbers. It covers hydraulic components including pump, control valve, cylinder, and oil lines. It is a parts reference, not a circuit or wiring diagram manual.
