Every Kubota B7200E repair starts the same way: you need the right part number before anyone takes your money. This Parts Catalog (OEM #100K0101) gives you 188 pages built around that single task. Thirty-two pages cover engine components from crankcase through governor; another 28 walk the drivetrain from transmission case to rear differential; the hydraulic pages add exploded diagrams for the lines and valves. Each section pairs a numbered parts list with its exploded view, showing quantity, serial-number breaks, and country-code remarks. Weights come straight from the catalog, not guesswork: 26 kgf for the crankcase assembly, 9 kgf for the cylinder head, 2.1 kgf for the injection pump. Load it on a tablet, bookmark your way to the system in question, and order correctly the first time.
What's Inside This Kubota B7200E Parts Manual
| System | Pages |
|---|---|
| Crankcase | 5-6 |
| Oil Pan | 7-8 |
| Cylinder Head | 9-10 |
| Gear Case | 11-12 |
| Main Bearing Case | 13-14 |
| Cylinder Head Cover | 15-16 |
| Manifold | 17-18 |
| Valve/Rocker Arm | 19-20 |
| Camshaft | 21-22 |
| Piston/Crankshaft | 23-24 |
| Flywheel | 25-26 |
| Injection Pump | 27-28 |
| Nozzle Holder | 29-30 |
| Engine Stop Lever | 31-32 |
| Speed Control Plate | 33-34 |
| Governor | 35-36 |
| Hydraulic Pump | 37-38 |
| Dynamo | 39-40 |
| Water Flange | 41-42 |
| Water Pump | 43-44 |
| Injection Pump [Section Parts] | 45-46 |
| Nozzle Holder [Section Parts] | 47-48 |
| Dynamo [Section Parts] | 49-50 |
| Hydraulic Pump [Section Parts] | 51-52 |
| Transmission Case | 53-54 |
| PTO Cover | 55-56 |
| Cover | 57-58 |
| Case Cover | 59-60 |
| Rear Axle Case | 61-62 |
| Clutch Rod | 63-64 |
| Clutch | 65-66 |
| 2nd Shaft | 67-68 |
| 3rd Shaft | 69-70 |
| 4th Shaft,5th Shaft | 71-72 |
| Spiral Bevel Shaft | 73-74 |
| PTO Shaft | 75-76 |
| Reverse Shaft | 77-78 |
| Rear Differential | 79-80 |
| Rear Axle | 81-82 |
| Rear Wheel (9.5-16) | 83-84 |
| Rear Wheel (8-16) | 85-86 |
| Rear Wheel (29 X 12.00-15) | 87-88 |
| Rear Wheel (31 X 13.5-15) | 89-90 |
| Rear Wheel Hub | 91-92 |
| Speed Change Fork | 93-94 |
| Main Speed Change | 95-96 |
| Aux. Speed Change | 97-98 |
| Rotary Speed Change Fork | 99-100 |
| Brake | 101-102 |
| Hydraulic Pipe | 103-104 |
| Hydraulic Block | 105-106 |
| Hydraulic 1 | 107-108 |
| Hydraulic 2 | 109-110 |
| Steering | 111-112 |
| Speed Change Lever | 113-114 |
| Brake Rod | 115-116 |
| Pedal | 117-118 |
| Release Rod | 119-120 |
| Seat | 121-122 |
| Label | 123-124 |
| Clutch Housing/Step/Starter | 125-126 |
| Front Axle Frame | 127-128 |
| Radiator | 129-130 |
| Fender | 131-132 |
| Hood | 133-134 |
| Battery | 135-136 |
| Muffler and Muffler Pipe [A],[CA] | 137-138 |
| Fuel Tank | 139-140 |
| Fuel Pipe | 141-142 |
| Fuel Filter | 143-144 |
| Panel | 145-146 |
| Panel Switch | 147-148 |
| Decompress Wire and Engine Stop Wire | 149-150 |
| Flasher Light/Tail Light/Head Lamp | 151-152 |
| Air Cleaner | 153-154 |
| Front Axle | 155-156 |
| Front Wheel Hub | 157-158 |
| Front Wheel (5.00-10) | 159-160 |
| Front Wheel (18 X 9.50-8) | 161-162 |
| 3-Point Linkage | 163-164 |
| Dynamo 1 [Option] | 165-166 |
| Dynamo 2 [Option] | 167-168 |
| Position Control Valve [Option] | 169-170 |
| Hydraulic Outlet [Option] | 171-172 |
| Horizon Muffler [Option] | 173-174 |
| Working Light [Option] | 175-176 |
| Flange F.Pto [Option] | 177-178 |
| Control Valve [Section Parts] | 179-182 |
| Starter [Section Parts] | 183-184 |
| Accessories and Service Parts | 188 |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| COMP.CRANKCASE Weight | 26 kgf | p. 6 |
| OIL PAN Weight | 1.1 kgf | p. 8 |
| COMP.CYLINDER HEAD Weight | 9 kgf | p. 10 |
| ASSY PUMP,INJECTION Weight | 2.1 kgf | p. 28 |
| ASSY BRAKE Weight | 5.14 kgf | p. 102 |
| ASSY STEERING Weight | 7.5 kgf | p. 112 |
| ASSY SEAT (S.No. <=20000) Weight | 8 kgf | p. 122 |
| FRAME,FRONT AXLE (S.No. <=20000) Weight | 25 kgf | p. 128 |
| ASSY RADIATOR Weight | 4.5 kgf | p. 130 |
| ASSY TANK,FUEL Weight | 2.9 kgf | p. 140 |
| ASSY 3-POINT LINKAGE (S.No. <=10578) Weight | 28 kgf | p. 164 |
Kubota B7200E Common Problems This Manual Covers
Kubota B7200E cracked or leaking hydraulic hoses on the main loader circuit. p. 103
Review the hydraulic pipe exploded view on page 103 to identify replacement hose part numbers. Match the correct line routing to your specific machine. If replacing the entire steering assembly nearby, note the 7.5 kgf weight spec on page 112 for safe lifting before ordering.
Manual Section: Hydraulic PipeSloppy or unresponsive loader bucket control valve linkage requiring replacement pivot pins and joints. p. 179
Check the control valve section parts breakdown on page 179 to find the exact linkage part numbers. Verify your machine serial number against the parts index. If ordering a complete 3-point linkage assembly instead, prepare for the 28 kgf weight listed on page 164.
Manual Section: Control Valve [Section Parts]Engine overheating due to a damaged radiator assembly and leaking coolant lines. p. 129
Locate the radiator components and mounting hardware on page 129. Order the correct replacement hoses and clamps from the parts list. When receiving the complete new radiator assembly, verify it matches the 4.5 kgf weight specification shown on page 130 before installation.
Manual Section: RadiatorPoor stopping power indicating worn brake shoes and internal hardware needing replacement. p. 101
Inspect the brake exploded view on page 101 to identify the correct part numbers for shoes, springs, and linkage. Cross-reference the components with your serial number. The complete brake assembly parts list notes a 5.14 kgf weight on page 102 for shipping calculations.
Manual Section: BrakeFrequently Asked Questions
How will I receive this Kubota B7200E Parts Catalog?
Download the 188-page searchable PDF right after purchase. It opens on any device, so you can pull it up on your phone while you're under the hood. No shipping, no waiting.
Are there any print restrictions on this Kubota B7200E manual?
None. With no DRM restrictions, you can print any page or section you need for your shop on any standard printer.
Does this Kubota B7200E Parts Catalog cover the hydraulic system?
It does. You'll find exploded diagrams and parts lists for hydraulic components including pumps, pipes, and control valves.
Document Quality
This document is a hybrid PDF, featuring searchable text for instructions and part lists, but diagrams are embedded as images. You can search and copy text from the instructional and tabular part list pages. The text on the instructional pages and within the part number tables is crisp and clear. Diagrams and illustrations are raster images, meaning they may appear pixelated when highly magnified, but their labels are generally readable at normal viewing sizes. All pages are clean with no noticeable scan artifacts, stains, or skewed content, and there are no blank pages, though some pages have significant whitespace due to diagram placement.
