Seventy-four pages, one machine: the LA344 and LA344S front loader, from boom cylinder teardown through hydraulic circuit diagnosis. The hydraulic schematics map the full front remote hydraulic control system, and 10 pages of exploded views break down boom cylinders, bucket cylinders, and piston rod assemblies. Wiring diagrams are included. Troubleshooting walks the fault paths for the front hydraulic valve main switch, the 3rd function solenoid valve, and the auto-lock attachment system, backed by a tightening torque table for general screws, stud bolts, hydraulic fittings, and plugs. Fill the transmission case to 11.3 L with Kubota SUPER UDT, then run M8 fasteners to 18-20 N·m before bolting the loader back on. When your loader is down, this is the factory answer rather than a forum guess. Every section is bookmarked and the text is searchable, so it pulls up fast on a tablet at the machine.
What's Inside This Kubota LA344, LA344S Manual
| System | Pages | Key Topics |
|---|---|---|
| 1. Information | 5-19 | Safety First (Before You Start Service, Start Safely, Operate Safely, Prevent A Fire, Keep A Good Airflow In The Work Area, Discard Fluids Correctly, Prevent Acid Burns, Prepare For Emergencies) |
| 2. General | 20-36 | Identification (Loader Identification), Lubricating System (Lubricants) |
| 3. Front Loader | 37-71 | Front Guard, Front Hydraulic Valve Main Switch, Front Loader, Front Remote Hydraulic Control System |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| General use screws, bolts, and nuts (M6, Ordinariness) | 7.9 to 9.3 N·m (0.80 to 0.95 kgf·m, 5.8 to 6.8 lbf·ft) | p. 27 |
| General use screws, bolts, and nuts (M8, Ordinariness) | 18 to 20 N·m (1.8 to 2.1 kgf·m, 13 to 15 lbf·ft) | p. 27 |
| Transmission Case Capacity | 11.3 L | p. 25 |
| Transmission Case Lubricant Type | KUBOTA SUPER UDT fluid | p. 25 |
| Grease Fitting Lubricant Type | Moly Ep type grease | p. 25 |
| General Bolt Torque (M10 Ordinariness) | 40 to 45 N·m | p. 27 |
| Hose Fitting Flare Nut Torque (UNF 3/4) | 36 to 40 N·m | p. 29 |
| Main Frame Mounting Bolt Torque (M14) | 115 N·m | p. 50 |
| Hydraulic Pump Flow | 23.5 L/min. | p. 39 |
| Relief Valve Pressure | 12.3 to 12.7 MPa | p. 39 |
| Boom Cylinder Stroke | 326 mm | p. 41 |
| Bucket Cylinder Stroke | 196 mm | p. 41 |
Kubota LA344, LA344S Common Problems This Manual Covers
Kubota LA344 hydraulic pump grinding noise after 500 hours, front loader boom will not lift or lifts slowly p. 48
Inspect the hydraulic pump and control valve per the troubleshooting procedures on page 48. Test the pump output to confirm it reaches 23.5 L/min. Check the transmission case fluid level and add KUBOTA SUPER UDT fluid if it falls below the 11.3 L capacity.
Manual Section: Front Loader Boom Operation IssuesFront end loader drifts downward while parked and boom falls by its own weight p. 70
Examine the boom cylinder tube and piston seals for internal wear. Remove the cylinder from the loader frame and measure the piston rod straightness; the bend must not exceed the 0.25 mm allowable limit shown on page 70. Replace damaged seals and reassemble.
Manual Section: Front End Loader Falling by its WeightBucket breakout force feels weak and bucket cylinder extends too slowly during material handling p. 29
Test the system relief valve pressure and adjust it to reach 12.3 to 12.7 MPa. Verify the bucket cylinder stroke reaches the full 196 mm specification. If you find leaks at the connections, torque the UNF 3/4 hose fitting flare nuts to 36 to 40 N·m as listed on page 29.
Manual Section: Front Loader Bucket Operation IssuesPopping noise from the loader bracket during heavy lifting and loose main frame mounting bolts p. 31
Check the main frame mounting bolts every 50 hours as specified in the maintenance schedule on page 31. Re-tighten the M14 mounting bolts to exactly 147 N·m to stop bracket movement. Replace any stretched hardware and verify all connections are secure before returning the machine to service.
Manual Section: 2. GeneralFrequently Asked Questions
What are the recommended service intervals?
Check hydraulic hoses daily, grease every fitting at 10-hour intervals, and inspect the main frame mounting bolts every 50 hours. Pages 2-13 and 2-14 give the full procedures.
What fluids and capacities does this machine require?
The transmission case takes 11.3 L (2.99 U.S.qts, 2.5 Imp.qts) of KUBOTA SUPER UDT fluid. Pack the grease fittings with Moly Ep grease until it overflows; that is an "Extreme pressure" grease containing molybdenum disulfide.
What are the hydraulic system specifications?
Flow runs 23.5 L/min (6.2 U.S.gals/min.) at item (1), with pressure at 12.3 to 12.7 MPa (1780 to 1840 psi) for item (4) and 0.5 MPa (150 to 180 psi) for item (6). Item (9) sends 9.5 L/min (2.5 U.S.gals/min.) to the power steering controller and routes excess flow to the front loader.
What torque specifications are listed?
Torque values vary by fastener. General M8 bolts take 18 to 20 N·m and M14 bolts 108 to 125 N·m, while R1/8 tapered plugs need 13 to 21 N·m. Hydraulic fittings such as the 9/16 UNF adjustable elbow run 37 to 44 N·m. On the loader itself, the boom cylinder piston mounting nut is 150 to 180 N·m, the bucket cylinder piston mounting nut 350 to 400 N·m, and the main frame mounting bolt (M14) 115 N·m.
How quickly can I access this Kubota LA344, LA344S manual after buying?
Immediate download of the complete 74-page searchable Workshop Manual. Open it on any device, whether that's the laptop at your desk or the phone out in the field.
Can I print this Kubota LA344, LA344S manual?
Yes, print as many copies as you want; there are no restrictions. Plenty of mechanics print just the section they need and carry it to the shop floor.
Are there wiring harness diagrams in this Kubota LA344, LA344S manual?
Yes. The manual includes electrical wiring diagrams for components like the front hydraulic valve main switch and the 3rd function solenoid valve.
Document Quality
This is a scanned document with an optical character recognition (OCR) layer, allowing you to search and copy the full text. The text is crisp and clear throughout, making it easy to read. Diagrams and illustrations are clear raster images, and their labels are readable. The pages are clean with no significant scan artifacts or marks, though several blank pages are included as section separators.
