Need the right part number for your 1988-1992 Ford tractor loader? This 356-page Ford 445C parts catalog PDF covers the 445C along with the 345C, 345D, 445D, 545C, and 545D. Every assembly gets an exploded view with numbered callouts tied to factory part numbers: front axle and steering, transmission gears and PTO, hydraulic lift cylinders, loader control valve, bucket and subframe, right down to seat cushions and safety decals. Seal kits, gear sets, and shim packs are broken out piece by piece, so you can order a single seal instead of a whole assembly. Identify your hydraulic pump by its 1600 PSI rating, then pick shims in exact 0.5 mm and 1.0 mm sizes. Ordering the wrong part twice kills a week. Bookmarked and keyword-searchable: jump to the diagram, read the number, order once.
What's Inside This Ford New Holland 345C–545D Series Parts Manual
| System | Pages | Key Topics |
|---|---|---|
| Fuel System | Fuel Sedimenter & Filter Assembly, Non-Emmissionized, Fuel Injector Assembly, Fuel Injection Pump, Dpa Rotary, Upper Half, Lower Half, Air Cleaner Assembly for Non-Emissionized Engine | |
| Cooling System | Radiator & Fan, Water Pump | |
| Engine | Hydraulic Reservoir & Pump Drive, Non-Emissionized Engine, Cylinder Block & Head, Crankshaft & Flywheel, Camshaft, Rocker Arm & Valves, Pistons & Connecting Rods, Oil Pump & Pan, Transmission Oil Cooler, Battery & Support, Engine Hood, Engine Grille, Non-Emissionized Engines, Lubricants - Lubrication Equipment, Engine Coolant Heater Kit, Accessory, Loader Hydraulics, Non-Emmisionized Engines | |
| Electrical System | Switch, Transmission Control Valve Pedal & Rel, Headlamp Assembly, Front Mounted L/Cab - N.a. Only, Flat Top Fender L/Cab - N.a. Only, Rear Lamps L/Cab - N.a. Only, Lamp Assembly, Emergency Warning L/Cab - N.a. Only, Flasher Warning L/Cab - N.a. Only, Implement Lamp Assembly L/Cab - N.a. Only, Implement Lamp, L/Cab, Na Only, Alternator Assembly, Horn Accessory Kit, D.i.a., Stop & Tail Lights, Stop & Tail Lamp, W/four Post ROPS, Lamp Assembly - License Plate | |
| Clutch & Transmission | Brake Controls - L/8x8 Transmission, Brake Controls - W/8x8 Transmission, Clutch Controls, Single Clutch Assembly, 13", Transmission Valve, Tubes & Fittings, 4 X 4 & 8 X 8, Transmission Case, 4 X 4, Transmission Rear Cover, Transmission Front Cover, Transmission Valve & Housing, Transmission Clutch & Input Shaft, Transmission Countershaft & Gears - 4 X 4, Transmission Output Shaft & Gears, Shift Fork & Rail, 1 & 2, W / 4 X 4, 3 & 4, W/4 X 4, Transmission Shift Lever & Dipstick, 8 X 8 | |
| PTO | Differential Lock & PTO Control, W/Cab, Independent PTO Assembly, FWD Related Parts L/pto, PTO Guard, PTO Shaft & Gears, 8 X 8 | |
| Rear Axle, Differential & Brakes | Standard Rear Wheels, Handbrake Lever W/twin Cable, Rear Axle, Differential, W/4wd, Differential Lock Linkage, Manifold Assembly, Rear Axle Hydraulic | |
| Front Axle & Steering | Front Wheel Assembly, Front Axle, Steering, 2WD, 4WD, Steering Column & Motor, 12/88-4/98, Power Steering Pump & Reservoir, Power Steering Cylinder Assembly - Trw, Power Steering Cylinder Assembly - "Cascade" | |
| Hydraulics & 3-Point Hitch | Hydraulic Lift Cover, Hydraulic Lift Shaft & Related Parts, Hydraulic Lift Cylinder, Flow Control Valve Piping, Flow Control Valve, Hydraulic Lift Linkage, Swinging Drawbar Assembly, Valve Assembly, Loader Control, Lift & Draft Control - W/Cab, Hydraulic Lift Control, Remote Controls, W/Cab, Remote Control Valve & Coupler, Coupling Assembly - Remote Control, Unload Valve, Hydraulic Pump Assembly, Gear Type, Mounted in Center Housing | |
| Loader, Backhoe & Attachments | Stabilizer Kit - W/loader, Decals - Loader, Bucket Assemblies | |
| Body & Operator Station | Throttle Controls, L/Cab, W/Cab, Kit, Turn Signal, Dia, Na Only, Seat Assembly, Michigan Seat, Grammer, Fenders, Mirror Assembly - Rear View - L/Cab - D.i.a., Subframe Assembly | |
| Decals & Accessories | Decals, Identificaton, Instructions, Warning & Caution, Shift Pattern Decals | |
| Other Components | Front End Weights, Center Housing, Box Assembly - Lift Leveling, Plugs - Block, Manifold & Exhaust System, Non-Emissionized, Reverse Idler Shaft & Gear, 4 X 4 & 8 X 8, Water Filter, Diesel Cold Start, Starting Motor Assembly, D.i.a., Back-Up Alarm, Instrument Cluster, Platform, Reflectors, Roof, Rollbar Kits, Safety, Paints |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| Pump & Reservoir Assy. Pressure | 1600 PSI | p. 27 |
| Thermostat, Standard | 168° | p. 123 |
| Shim, 0.5mm | 0.5mm | p. 196 |
| Shim, 1.0mm | 1.0mm | p. 196 |
| Pump & Reservoir Assy. Flow Rate | 2.74 U.S. Gal. at 1000 RPM | p. 27 |
| Thermostat Temperature | 168° | p. 123 |
| Alternator Output | 51 AMP | p. 276 |
Ford New Holland 345C–545D Series Common Problems This Manual Covers
Ford 445C power steering pump leaking at the reservoir, can't identify the right seal kit
Check the Power Steering Pump & Reservoir exploded view starting on page 26. Match your pump against the gear set, seal, and valve assembly callouts, then pull the seal numbers from the parts list. Verify the replacement pump is the unit rated 1600 PSI, shown on page 27, and note your serial number before ordering.
Manual Section: Power Steering Pump & Reservoir p. 26Hydraulic lift cylinder weeping at the rod, need the correct seal kit part number
Check the Hydraulic Lift Cylinder exploded view on page 76 and match your cylinder against the tube, rod, piston, and gland callouts. The seal kit is listed as its own line item in the parts list. Confirm the seals suit the 1600 PSI pump pressure shown on page 27 before you order anything.
Manual Section: Hydraulic Lift Cylinder p. 76Engine runs cold in winter, not sure which replacement thermostat the parts list calls for
Check the thermostat listing on page 123: the standard unit is rated at 168 degrees. Match that temperature rating when cross-referencing aftermarket numbers, because a hotter or colder element changes running temperature. Find the housing and gasket callouts on the engine parts diagram on page 122 and order the gasket with the thermostat.
Manual Section: Engine Parts Diagram p. 123Battery not charging, unsure whether the tractor came with the 51 amp or 70 amp alternator
Verify the amperage stamped on your alternator tag before ordering anything. The 51 AMP unit is cataloged on page 276, while the 55 Amp and 70 Amp versions appear on page 279. Match the pulley and mounting bracket callouts in the exploded view, then confirm your serial number range in the parts list.
Manual Section: System 118 p. 276Transmission solenoid replacement, can't tell which shim thickness goes back in during reassembly
Measure the shim you removed with calipers before ordering; the parts list on page 196 catalogs both 0.5mm and 1.0mm thicknesses under separate part numbers. Order both sizes if the old shim is damaged beyond measuring, then match the original stack height at reassembly. Confirm the solenoid part number against your serial range in the same list.
Manual Section: System 81 p. 196Frequently Asked Questions
What are the replacement specifications for hydraulic couplers?
The hydraulic coupler used for remote hydraulic systems is the Snap-Tite #6800. This part is identified by part number 86508779. p. 110
What is the capacity of the hydraulic reservoir?
The hydraulic pump and reservoir assembly has a capacity of 2.74 U.S. Gallons at 1000 RPM. p. 27
What is the correct belt length for the radiator fan?
The radiator fan belt has a length of 55.26 inches. p. 217
What is the torque specification for the cylinder head bolts?
The cylinder head bolts are 9/16"-12 x 5 1/32" and are listed as part number 87802206. p. 123
What is the thermostat temperature rating for the engine?
The standard thermostat for the engine is rated at 168 degrees Fahrenheit. p. 123
What format is this Ford 445C & variants manual in?
Instant PDF download. You get the full 356-page searchable Parts Catalog immediately after payment. Open it on your laptop, tablet, or phone right in the shop.
Can I print specific sections of this Ford 445C & variants Parts Catalog?
Yes. The PDF has no DRM restrictions, so print any page or section you need for your shop. Works with any standard printer.
