Part of the New Holland Repair Manuals.
Every one of the 882 pages in this New Holland Tractor Repair Manual targets the 4835, 5635, 6635, and 7635 models, covering everything from engine teardown to PTO clutch service. You get full electrical circuit diagrams for the starting and charging systems, hydraulic schematics for the rear mechanical lift and remote auxiliary control valves, and a dedicated troubleshooting section for engine faults before you start pulling parts. Check your PTO clutch release spring under a 67.6 kg load, and confirm the alternator tops out at 45A before you chase a phantom charging complaint. Stop swapping components on a hunch. This PDF opens on laptop, tablet, or phone, with bookmarks built in so you can jump straight from the cover to the wiring or hydraulic sections and get back under the hood.
What's Inside This New Holland 4835, 5635, 6635, 7635 Repair Manual
| System | Pages | Key Topics |
|---|---|---|
| General Information | 5-82 | Safety Rules, Consumables, Engine Specifications, Battery Specifications, Rear Mechanical Hydraulic Lift Specifications, Remote Auxiliary Control Valves Specifications |
| Engine | 83-218 | Engine Troubleshooting, Engine - Removal, Engine - Installation, Engine - Disassembly, Engine - Assembly |
| Electrical System | 219-340 | Instruments, Components, Starting System, Charging System, Battery, Electrical Circuits |
| High Pressure Hydraulic System | 341-414 | Rear Mechanical Hydraulic Lift, Remote Auxiliary Control Valves, Supplementary Cylinder |
| Low Pressure Hydraulic System | 415-476 | Braking System, Steering System |
| Power Train | 477-674 | Clutch, Mechanical Transmission, Reverser, Overdrive Unit, Hi-Lo Unit, Reverser and Creeper Unit, Drive Lines, Rear Mechanical Wheel Drive |
| Front Axle | 675-734 | Front Axle and Wheels, Front Axle Mechanical Transmission |
| PTO | 735-774 | Contents, Power Take-Off with Electro-Hydraulic Engagement, Main Data - Power Take-Off with Electro-Hydraulic Engagement (RPM PTO) |
| Cab | 775-800 | Interior Panel Trim, Levers, Seat, Electrical Controls - Removal, Electrical Controls - Reassembly |
| Air Conditioning | 801-850 | Cab Air Conditioning System, Use of the Air Conditioning System |
| Special Tools | 851-882 | Engine Special Tools, Hydraulic Lift Equipment Special Tools, Open Center System Auxiliary Control Valves Special Tools, Remote Auxiliary Control Valves Special Tools |
Every system also includes an index.
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| 65 hp and 75 hp | ||
| Radiator type (65 hp and 75 hp models) | 3-row vertical pipes with copper fins | p. 14 |
| 85 hp and 95 hp | ||
| Radiator type (85 hp and 95 hp models) | 4-row vertical copper pipes | p. 14 |
| All Models | ||
| Coolant pump type | centrifugal vane-type | p. 14 |
| Engine speed/coolant pump speed ratio | 1:1.403 | p. 14 |
| Alternator (MAGNETI MARELLI AA125R-14V-65A) - Maximum output | 45 A | p. 251 |
| Fuel filtering system | through wire filter in fuel supply pump, and replaceable cartridge on delivery line to injection pump | p. 15 |
| Engine oil cleaning system | mesh screen on oil pick-up and filter cartridge in delivery line | p. 13 |
| Engine Valve Clearance for Timing Check | 0.45 mm (0.0177 in.) | p. 14 |
| 65 hp, 75 hp | ||
| Engine Piston Diameter | 100 mm (3.937 in.) | p. 12 |
| Engine Total Displacement | 3613 cm³ | p. 12 |
| 85 hp, 95 hp | ||
| Engine Piston Diameter | 104 mm (4.094 in.) | p. 12 |
| Engine Total Displacement | 3908 cm³ | p. 12 |
New Holland 4835, 5635, 6635, 7635 Common Problems This Manual Covers
New Holland 4835/5635/6635/7635 hydraulic lift arm losing pressure and rising too slowly under load
Check the hydraulic schematic to trace the charge pump, high-pressure pump, and valve block circuit. Watch for lift speed dropping off after 10 to 20 minutes of operation, a sign the charge pump seal is failing as oil heats up. Remove the pump and replace worn seals before they starve the main pump.
Manual Section: High Pressure Hydraulic SystemEngine temperature climbs above normal and overheats during heavy field work in high heat
Check the engine troubleshooting chart for overheat causes. Inspect the radiator core for clogging and confirm the centrifugal vane-type coolant pump is turning at the correct 1:1.403 ratio to engine speed; a slipping belt or worn pump throws that ratio off fast. Flush the cooling system and replace the thermostat if coolant still climbs.
Manual Section: Engine p. 14Electrical components fail intermittently, lights and gauges cut out or won't start
Check the alternator output against its 45 A maximum rating listed on page 251; a unit reading below spec under load can't keep the battery charged and will drop lights and gauges intermittently. Inspect the wiring harness for chafed insulation near pivot points, clean all ground straps, and load-test the battery before condemning the starter motor.
Manual Section: Electrical System p. 251Engine won't start, runs rough, or knocks under load at working RPM
Check the engine troubleshooting sequence first to rule out fuel and compression issues. Verify valve clearance against the 0.45 mm (0.0177 in.) timing check spec on page 14; clearance out of range causes rough running and knocking that mimics injector or bearing failure. Reset clearance and retest before pulling the head.
Manual Section: Engine p. 14Transmission gear engagement is difficult or fails under load in the field
Verify displacement matches spec, 3613 cm³ on 65 hp models or 3908 cm³ on 85 hp models per page 12, to rule out engine-side power loss mimicking a clutch slip before condemning the clutch. If engine output checks out, inspect the clutch disc for glazing and adjust linkage free play, then road-test in each range.
