This 417-page New Holland LW110, LW130 Service Manual PDF covers the LW110, LW130, and LW130TC wheel loaders from engine to cab, with nothing left out. Open it up and you get full electrical system wiring diagrams, equipment hydraulic schematics for the oil circuit and control valve, and a torque table covering everything from wheel nuts to steering components. You also get exploded views for the transmission and axle teardown, plus a troubleshooting section built for real diagnostic work, not guesswork. Torque your wheel nuts to 86.2 daNm (627 ft-lbs) and check brake disc thickness against the 5.9 to 6.5mm spec before you call it done. No more flipping through three different photocopies trying to find the right number. Grab it on your phone, jump straight to the section you need with the built-in bookmarks, and get back under the machine.
What's Inside This New Holland LW110, LW130, LW130TC Manual
| System | Pages | Key Topics |
|---|---|---|
| Specifications | 12-16 | Engine, Axles, Tyres, Torque Converter, Brakes, Transmission |
| Capacities and Fluid Types | 17 | Engine, Cooling System, Transmission, Hydraulic and Brake System, Front Axle Oil, Rear Axle Oil |
| Safety Rules | 18-24 | Personal Safety, Machine Safety, Safety Precaution Information, Avoid Accidents, Operating |
| Units of Measure Used in the Manual/Tightening Torques | 25-27 | Force, Pressure, Torque, Standard Index Digit, Material Index Digit, Torque Tables |
| Engine | 28-57 | General Description, General Specifications, Data - Mounting Clearances, Injection Pump Setting Data, Lubrication System, Cooling System |
| Drive Line/Transmission | 58-219 | General Description, Torque Converter, Transmission, Disassembly/Reassembly Transmission, Oil Circuit, Front and Rear Axles |
| Braking System | 220-245 | General Description, Operation, Disc Brake, Brake Pedal Valve, Parking Brake, Diagnostics and Testing |
| Steering System | 246-267 | General Description, Principles of Operation of Main Priority Valve, Steering Valve (Orbitrol), Steering Cylinders, Multiple Check Valve |
| Bucket Booms and Frame | 268-277 | Load Handling System, Booms, Bellcrank, Bucket, Frame Pivot Pins, Bucket Roll |
| Equipment Hydraulic System | 278-325 | Oil Circuit, Hydraulic System Pump, Equipment Control Valve, Hydraulic Oil Reservoir, Cylinders, L.T.S. Anti-Pitching System |
| Electrical System | 326-389 | General Lay-Out, Logic Board, Fuses, Connectors, Cab Instrument Cluster, Switch Panel |
| Cab | 390-417 | Windscreen Wipers and Washers, Heater, Glasses, Repair, Air Conditioning Unit, Troubleshooting |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| Tightening torque of wheel nuts | 86.2 daNm (627 ft-lbs) | p. 221 |
| Brake disc thickness | 5.9 + 6.5 | p. 216 |
| Brake ring thickness | 6.38 + 6.50 | p. 216 |
| Tightening torque | 10.5 daNm | p. 271 |
| Diameter of upper pivot pin | 59.981 + 60.000 | p. 276 |
| Diameter of lower pivot pin | 74.966 + 74.985 | p. 276 |
New Holland LW110, LW130, LW130TC Common Problems This Manual Covers
New Holland LW130 loader boom drops slowly on its own after being raised and left unsupported for service
Check the boom pivot pins for wear before raising for service; the upper pin should measure 59.981 to 60.000 mm and the lower pin 74.966 to 74.985 mm per page 276. Install mechanical blocks or support pins before working underneath the boom, since lift cylinders alone can drift or fail under load. Replace pins measuring under spec.
Manual Section: Bucket Booms and Frame p. 276Wheel nuts back off or rim retainers crack after repeated heavy loader duty
Torque wheel nuts to 86.2 daNm (627 ft-lbs) as specified on page 221, and recheck before every working shift, not just after service. Loose retainers let the rim walk under load and shear the studs. Use a calibrated torque wrench in a star pattern and inspect for stud stretch or elongated bolt holes.
Manual Section: Braking System p. 221Exhaust fumes or heat build up in the operator cab during extended operation inside an enclosed building
Verify the building has ventilation rated to clear exhaust gases before running the engine indoors; carbon monoxide buildup is a serious hazard covered in the safety rules on page 18. Open bay doors or install exhaust extraction ducting, and shut down immediately if cab air quality feels off.
Manual Section: Safety Rules p. 18Machine feels unstable or skids during low speed travel with the brakes applied
Check brake fluid pressure and pedal free travel before each shift; low pressure or a misadjusted pedal valve causes uneven braking and skidding. On LW110, minimum brake disc thickness is 5.9 mm and brake ring thickness is 6.38 mm per page 216; replace discs below this limit and bleed the system per the braking system section starting page 220.
Manual Section: Braking System p. 216Starter motor cranks slowly or fails to engage when the ignition key is turned
Check the starter mounting bolts for looseness first; they should be torqued to 10.5 daNm on page 271, and a loose starter will crank erratically or fail to engage the flywheel. Clean the battery terminals, verify full battery voltage under load, and inspect the starter solenoid contacts for pitting before replacing the starter assembly.
Manual Section: Bucket Booms and Frame p. 271Frequently Asked Questions
What is the engine oil capacity for the New Holland LW110 wheel loader?
The total engine oil capacity for the first filling of the New Holland LW110 is 14.5 Kg. For periodic changes, the engine sump capacity is 12 Kg, and with the filter, it is 13.2 Kg. p. 33
What is the nominal pre-charge pressure for the brake accumulator?
The brake accumulator should be pre-charged with NITROGEN gas. The nominal pre-charge pressure for the brake accumulator is 2.8 kg abt. p. 237
What is the maximum engine power for the New Holland LW110 wheel loader?
The New Holland LW110 wheel loader has a maximum engine power of 83 KW, achieved at an engine speed of 2300 rpm. p. 32
What is the front axle oil capacity for the New Holland LW110 wheel loader?
The front axle oil capacity for the New Holland LW110 wheel loader is 18 liters. This information is provided in the 'Fluids and Capacity Table'. p. 17
What do I get after purchasing this New Holland LW110, LW130, LW130TC manual?
This is a 417-page searchable PDF ready for immediate download. Works on any device, so pull it up on your phone while you're under the hood. No shipping, no waiting.
Can I print specific sections of this New Holland LW110, LW130, LW130TC manual?
Yes. The PDF has no DRM restrictions, so print any page or section you need for your shop. Works with any standard printer.
Can I find wiring schematics in this New Holland LW110, LW130, LW130TC manual?
Yes, full electrical schematics are included with wire colors, connector locations, and circuit descriptions.
