The JXU series are Case IH's utility workhorses, five tractors from the 76 hp JXU75 up to the 113 hp JXU115, all built on the F4CE 4.5 litre diesel. This is the real factory service manual with supplement, part 87679936A, 1,538 pages covering the engine, clutch, transmissions, front and rear mechanical drive, PTO, brakes, hydraulics, steering, cab air conditioning and the electrical system. Whether you are chasing weak lift power, an engine that stalls under load, or heavy steering, it is here in factory order with the per model ratings and the torque values to work to.
What's Inside This Case IH JXU75, JXU85, JXU95, JXU105, JXU115 Manual
| System | Pages | Key Topics |
|---|---|---|
| General Guidelines | Machine and Engine Specifications, Standard Torque Values, Fluids, General Service | |
| Engine | F4CE 4.5 Litre Four Cylinder Diesel Repair, Cylinder Head, Block, Timing, Lubrication, Cooling, Turbocharger | |
| Clutch | Clutch Assembly, Release Mechanism, Adjustment and Service | |
| Transmissions | Gearbox, Shuttle and Range, Shifting, Service and Specifications | |
| Drive Lines | Propeller Shafts, Universal Joints, Drive Line Service | |
| Front Mechanical Transmission | Front Wheel Drive Axle, Differential, Planetaries, Engagement | |
| Rear Mechanical Transmission | Rear Axle, Differential, Final Drives, Differential Lock | |
| Power Take-Off | Rear and Mid PTO, Speeds, Clutch and Engagement, Service | |
| Brakes | Service and Park Brakes, Brake Valves, Bleeding and Adjustment | |
| Hydraulic Systems | Hydraulic Pump, Control Valves, Three Point Hitch, Remote Couplers, Relief Settings | |
| Steering | Hydrostatic Power Steering, Pump and Valve, Cylinders, Linkage | |
| Axle and Wheels | Front Axle, Wheels, Tires, Tread Settings, Alignment | |
| Cab Air Conditioning | Heating and Air Conditioning, Compressor, Refrigerant, Controls | |
| Electrical System | Wiring Diagrams, Charging and Starting, Lighting, Instruments, Sensors | |
| Platform, Cab, Bodywork | Cab, Platform, Panels, Operator Controls, Bodywork |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| All models | ||
| Engine | F4CE 4.5 L (4485 cc) 4-cylinder direct-injection diesel | |
| Bore x Stroke | 104 x 132 mm | |
| Compression Ratio | 16.5:1 | |
| Cylinders | 4 in-line | |
| Production Years | 2007 to 2013 | |
| JXU75 | ||
| Max Power | 56 kW (76 hp) | |
| JXU85 | ||
| Max Power | 63 kW (86 hp) | |
| JXU95 | ||
| Max Power | 71 kW (97 hp) | |
| JXU105 | ||
| Max Power | 78 kW (106 hp) | |
| JXU115 | ||
| Max Power | 83 kW (113 hp) | |
Case IH JXU75, JXU85, JXU95, JXU105, JXU115 Common Problems This Manual Covers
Loss of hydraulic or lift power during heavy lifting
Weak lift or hydraulic power under load usually traces to the hydraulic pump, a low relief setting or a worn control valve. Check the system pressure and flow against spec, inspect the relief and the fluid level and condition, then service the pump if output is low. The hydraulic systems section gives the test points and pump procedure.
Manual Section: Hydraulic SystemsEngine stalls unexpectedly under load
A stall under load on the F4CE diesel is most often fuel delivery, a clogged filter or an air intake restriction. Change the fuel and air filters, check supply and injection delivery, and confirm the idle and rated speeds. The engine section covers the fuel and injection service and the speed settings.
Manual Section: EngineLoss of power steering or heavy steering
Heavy or lost steering points to the steering pump, a low relief or air in the system. Check the fluid level and condition, bleed the system, and test the steering pump and relief pressure against spec. The steering section covers the pump, valve and the pressure checks.
Manual Section: SteeringFrequently Asked Questions
What does Case IH part number 87679936A cover?
It is the full factory service manual with supplement for the Case IH JXU75, JXU85, JXU95, JXU105 and JXU115 tractors, 1,538 pages covering the F4CE 4.5 litre diesel, clutch, transmissions, front and rear drive, PTO, brakes, hydraulics, steering, cab air conditioning and the electrical system.
My JXU loses lift or hydraulic power under a heavy load, where do I start?
Loss of lift power under load usually points to the hydraulic pump, the relief setting or a worn control valve. The hydraulic systems section covers the pump, the pressure and flow checks and the relief settings to isolate it.
Does one manual cover all five JXU models?
Yes. The JXU75, JXU85, JXU95, JXU105 and JXU115 are covered together, with the per model engine ratings and any model specific differences called out within each procedure.
Which engine is in the JXU series and what power does each model make?
All five use the F4CE 4.5 litre four cylinder diesel. Output runs from 56 kW (76 hp) on the JXU75 up to 83 kW (113 hp) on the JXU115, with the exact rating per model in the engine section.
Is this the same manual a Case IH dealer uses?
It is the factory service manual with supplement (part number 87679936A), the same step by step repair, specification and torque data the JXU tractors were built and serviced to.
