All 391 pages of this Kubota BX2660 Workshop Manual PDF (OEM #9Y111-01951) are factory-written for the 2008-2009 BX1860, BX2360, and BX2660 tractors, plus their RCK rotary mower decks and LA203/LA243 front loaders. Inside: full hydraulic schematics for the hydrostatic transaxle, steering circuit, and implement system, plus wiring diagrams covering the starting, charging, lighting, and gauge circuits. You also get troubleshooting across engine, front axle, and hydraulic symptoms, exploded-view assemblies, and step-by-step service procedures spanning every system from PTO clutch to relief valve adjustment. Torque the front wheel screws to 149.2-179.0 N·m (110-132 lbf·ft) and the rears to 108.5-130.2 N·m (80-96 lbf·ft); LA203/LA243 loader frame bolts spec at 147 N·m (108 ft-lbs). Your tractor is down and the clock is running. Grab the PDF, jump straight to the system you need with bookmarks, search any spec by keyword, and get back to work.
What's Inside This Kubota BX1860 & variants Manual
| System | Pages | Key Topics |
|---|---|---|
| G General | 14-62 | Tractor Identification (Serial Number, Cylinder Number), Handling Precautions For Electrical Parts And Wiring (Battery, Fuse, Connector, Handling Of Circuit Tester), Lubricants |
| 1 Engine | 63-132 | Troubleshooting, Servicing Specifications (Bx1860, Bx2360, Bx2660), Tightening Torques, Checking, Disassembling And Servicing (Checking And Adjusting, Disassembling And Assembling) |
| 2 Transaxle | 133-201 | Structure, Traveling System (Hydrostatic Transmission, Range Gear Shift Section, Front Wheel Drive Section, Differential Gear Section, Brake Section) |
| 3 Front Axle | 202-221 | Structure, Front Wheel Alignment, Camber, Kingpin Angle, Caster, Toe-in, Separating Front Axle Assembly, Front Axle Assembly |
| 4 Steering | 222-236 | Hydraulic Circuit, Steering Controller, Steering Cylinder |
| 5 Hydraulic System | 237-268 | Hydraulic Circuit, Hydraulic Pump, Control Valve, Flow Priority Valve, Relief Valve, Hydraulic Cylinder, Hydraulic Block Type Outlet, Mower Linkage |
| 6 Electrical System | 269-313 | Wiring Diagram, Starting System (Main Switch Position, Safety Switch, Operator Presence Control), Charging System (Electrical Circuit, IC Regulator), Lighting System |
| 7 Mower | 314-352 | Mower Identification, Lubricants, Tightening Torques, Maintenance Check List |
| 8 Front Loader | 353-391 | Identification, Lubricants |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| All Models | ||
| Front wheel mounting screws tightening torque | 149.2 to 179.0 N·m (15.2 to 18.3 kgf·m, 110 to 132 lbf·ft) | p. 31 |
| Rear wheel mounting screws tightening torque | 108.5 to 130.2 N·m (11.1 to 13.3 kgf·m, 80 to 96 lbf·ft) | p. 31 |
| Hydraulic relief valve troubleshooting - Implement Does Not Rise (No Noise) / Relief valve spring damaged | Replace | p. 251 |
| Hydraulic relief valve troubleshooting - Implement Does Not Rise (Noise) / Relief valve setting pressure too low | Adjust or replace | p. 251 |
| Mower blade screw tightening torque | 103 to 117 N·m (10.5 to 12.0 kgf·m, 76.0 to 86.7 lbf-ft) | p. 345 |
| Mower belt replacement instruction | Replace the mower belt with a new one, if there is found surface split at more than 3 positions. | p. 344 |
| Transmission oil filter tightening instruction | Tighten the filter quickly until it contacts the mounting surface. Tighten filter by hand an additional 1/2 turn only. | p. 29 |
| Transmission oil filter replacement instruction | To prevent serious damage to the hydraulic system, use only a KUBOTA genuine filter. | p. 29 |
| Engine oil filter replacement interval | every 200 Hr | p. 26 |
| LA203, LA243 | ||
| Main frame mounting bolt and nut (M14) tightening torque | 147 N·m (15.0 kgf·m, 108 ft-lbs) | p. 364 |
| RCK48P-18BX, RCK54P-23BX | ||
| Pulley holder mounting bolt and nut tightening torque | 77 to 90 N·m (7.9 to 9.2 kgf·m, 57 to 67 lbf·ft) | p. 343 |
| RCK60B-23BX | ||
| Blade spindle speed | 44.1 r/s (2647 rpm) | p. 318 |
Kubota BX1860 & variants Common Problems This Manual Covers
Kubota BX2360 front loader boom lifts slowly or loses power under load p. 251
Check hydraulic fluid level first; transmission case capacity is 11.6 L (page 11). Trace and fix any leaks before refilling. Replace the hydraulic filter if overdue; tighten until it seats, then exactly 1/2 turn by hand (page 29). If fluid and filter are good, the hydraulic troubleshooting chart on page 251 covers relief valve pressure, pump output, and slow-boom conditions.
Manual Section: Front Loader TroubleshootingBlades leave strips of uncut grass or produce a ragged, uneven finish p. 345
Inspect all three blades for wear, cracks, or impact damage. Run the engine at full throttle; low RPM is the most common cause of poor cut. Torque blade screws to 103 to 117 N·m (page 345) after inspecting each one. Check tire pressure across all corners; uneven inflation tilts the deck. Replace the belt if surface splits appear at more than 3 positions (page 344).
Manual Section: Mower TroubleshootingEngine won't start or turns over slowly after extended storage or winter layup
Check battery condition first; a weak battery won't crank a diesel fast enough to fire. Drain and replace fuel that sat over winter; the 25 L tank (page 11) is easily contaminated during storage. Verify the air filter is clean and unrestricted. The engine troubleshooting procedures walk through no-start, slow cranking, and deficient output conditions.
Manual Section: Engine TroubleshootingMower deck vibrates excessively or makes a banging noise at operating speed p. 345
Remove the deck and inspect all three blades for bends, cracks, or impact damage; one damaged blade throws the whole assembly out of balance. Torque blade screws to 103 to 117 N·m (page 345); loose hardware quickly leads to spindle bearing failure. Clean packed grass and debris from under the deck thoroughly. If vibration persists after blade and hardware checks, inspect spindle bearings for wear.
Manual Section: Mower TroubleshootingEngine temperature climbs into the red during loader work or heavy mowing
Clean debris from the radiator screen and engine compartment; blocked airflow is the most common cause. Check fan belt deflection: 7.0 to 9.0 mm under moderate finger pressure at the midpoint (page 85). Verify engine oil is at the correct level. The engine troubleshooting procedures cover thermostat and coolant system checks if airflow and belt are good.
Manual Section: Engine TroubleshootingPTO clutch slips, engages late, or mower blades fail to reach operating speed p. 169
Verify PTO clutch operating pressure is within 1.0 to 1.3 MPa (page 169); low pressure is the primary cause of slip and slow blade engagement. Check hydraulic fluid level in the transmission case before pressure testing. If pressure stays low after topping off fluid, inspect the relief valve and clutch pack for wear. The PTO system troubleshooting index covers slip, no-rotation, and drag conditions.
Manual Section: PTO System TroubleshootingFrequently Asked Questions
How do I reset the mower deck on a Kubota BX with RCK48-18BX or RCK54-23BX?
The manual provides procedures for adjusting the mower deck's position and cutting height. For adjusting the mower link, ensure the clearance (L) between the stopper and rear link is 0 to 0.5 mm (0 to 0.01 in.). For adjusting front and rear cutting height, ensure the difference (R-F) between the front and rear blade tips is 0.0 to 5.0 mm (0.0 to 0.20 in.) by adjusting the length of the front link. Refer to pages 7-G13 and 7-G14 for detailed procedures.
What are the torque specs for Kubota BX1860 front loader bolts?
For the Kubota BX1860 front loader, the boom cylinder piston mounting nut should be tightened to 150 to 180 N·m (111 to 132 lbf·ft). The bucket cylinder piston mounting nut requires a torque of 350 to 400 N·m (259 to 295 lbf·ft), and the main frame mounting bolt and nut (M14) should be tightened to 147 N·m (108 lbf·ft).
What are the replacement specifications for mower blades?
The replacement specifications for mower blades vary by model. For the RCK60B-23BX, the blade length is 523 mm (20.6 in.). For RCK54P-23BX and RCK54-23BX, the blade length is 475 mm (18.7 in.). For RCK48P-18BX and RCK48-18BX, the blade length is 424 mm (16.7 in.). Blades should be replaced if worn or cracked, as shown in figure (3) on page 344.
What are the replacement specifications for blade screws/bolts?
The manual specifies tightening torques for mower blade screws. For RCK48-18BX, RCK54-23BX, and RCK60B-23BX models, the mower blade screw should be tightened to 103 to 117 N·m (76.0 to 86.7 lbf·ft). For RCK48P-18BX and RCK54P-23BX models, the mower blade screw should be tightened to 103 to 118 N·m (76 to 87 lbf·ft). The manual also advises replacing the screw if it is worn or broken, as indicated on page 7-G6.
What format is this Kubota BX1860 & variants manual in?
This is a 391-page searchable PDF ready for immediate download. Works on any device, pull it up on your phone while you're under the hood. No shipping, no waiting.
Are there any print restrictions on this Kubota BX1860 & variants manual?
Absolutely. No DRM or copy protection. Print the whole manual or just the pages you need. Any home or office printer works.
Can I find wiring schematics in this Kubota BX1860 & variants manual?
Complete wiring diagrams are included, covering all electrical circuits, harness routing, and connector pinouts for the Kubota BX1860 & variants.
Document Quality
This document is a scanned PDF, but an OCR layer has been applied, so you can search and copy the full text. The text is consistently crisp and easy to read throughout the manual. Diagrams and illustrations are raster images, but they are clear and their labels are readable. Pages are clean with no noticeable scan artifacts or skewed content. Be aware there are several blank or filler pages, typically serving as section dividers.
