Need the factory rebuild data for your Kubota M7-132, M7-152 or M7-172? This 1,709-page workshop manual (OEM #9Y111-19532) is Kubota's own service documentation for the M7-2 series - the V6108-CR-TIEF4 6.1L common-rail diesel, the 24-speed powershift and KVT continuously-variable transmissions, hydraulics, 3-point hitch, DEF/SCR after-treatment, cab electronics and the complete wiring. Every torque value, clearance, capacity and diagnostic step a tech needs, in a searchable PDF you keep for the life of the machine.
What's Inside This Kubota M7-132, M7-152, M7-172 Manual
| System | Pages | Key Topics |
|---|---|---|
| Information & General | Safety, Tractor Identification, Specifications, Dimensions, Lubricants & Coolant, Master Tightening Torques, Special Tools | |
| Engine - V6108-CR-TIEF4 | Common-Rail Injection, Turbo & Intercooler, Cooling, Lubrication, Disassembly & Rebuild, Clearances | |
| Fuel & Emissions (DEF/SCR) | Common-Rail Fuel System, DPF After-Treatment, SCR/AdBlue Dosing, Regeneration, Fault Codes | |
| Clutch & Transmission | 24-Speed Powershift (F30/R15), KVT Continuously-Variable, Range Shift, Calibration, Creep Option | |
| Front & Rear Axle | Final Drives, Front-Axle Suspension, Differential, Diff-Lock, 4WD Engagement | |
| Brakes & Steering | Hydrostatic Steering, Wet Brakes, Bleeding, Adjustment, Pressure Tests | |
| Hydraulics & 3-Point Hitch | Pump Flow (80/110 L/min), Load-Sensing, Relief Settings, Lift Capacity, Valve Service, 20 MPa System Pressure | |
| Electrical | Wiring Diagrams, Connector Pinouts, ECU/CAN, Fault Codes, Charging & Starting, Sensors | |
| Cab & HVAC | Climate Control, Controls, Instrument Cluster, Service Reminder Reset |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| All Models | ||
| Engine | Kubota V6108-CR-TIEF4 (4-cyl, common-rail DI, turbo + intercooler diesel) | |
| Total displacement | 6124 cm³ (374 cu.in.) | |
| Bore x stroke | 118 x 140 mm (4.65 x 5.51 in.) | |
| Fuel tank capacity | 330 L (87.2 U.S.gals) | |
| DEF/AdBlue capacity | 38 L (10 U.S.gals) | |
| Engine oil capacity | 22 L | |
| Coolant capacity | 24 L | |
| Hydraulic pump flow | 80 L/min (open-center) / 110 L/min (closed-center, load-sensing) | |
| 3-point hitch lift capacity | 9400 kg (20720 lbs) at lifting points | |
| Hydraulic system pressure | 20.0 MPa (208 kgf/cm²) | |
| Transmission | 24-speed (F30/R15) powershift, or KVT continuously-variable | |
| Weight | 6730 kg (powershift) / 6980 kg (KVT) | |
| M7-132 | ||
| Rated power | 84.6 kW (113 HP) / 2100 rpm | |
| M7-152 | ||
| Rated power | 99.3 kW (133 HP) / 2100 rpm | |
| M7-172 | ||
| Rated power | 114.0 kW (153 HP) / 2100 rpm | |
| M7-132 / M7-152 / M7-172 | ||
| Max power with boost | 148 / 168 / 173 HP @ 1900 rpm | |
| PTO power | 74.6 / 89.5 / 104.4 kW (100 / 120 / 140 HP) @ 2000 rpm | |
Kubota M7-132, M7-152, M7-172 Common Problems This Manual Covers
DEF/SCR or DPF warning lights and de-rate — failed regeneration, AdBlue quality/dosing faults on the V6108 after-treatment.
Use the emissions section to read the fault code, check AdBlue quality and the dosing module, and follow the manual's forced-regeneration and SCR diagnostic procedure.
Manual Section: Fuel & Emissions (DEF/SCR)KVT transmission shifting irregularly or throwing a transmission fault after service.
Follow the KVT calibration procedure in the transmission section and verify hydraulic/transmission oil to the correct capacity before re-testing.
Manual Section: Clutch & TransmissionElectrical warning lights / intermittent sensor faults the dash won't explain.
Use the wiring diagrams and connector pinouts to trace the circuit, then run the section's sensor and ECU/CAN checks against the listed values.
Manual Section: ElectricalFrequently Asked Questions
How do I reset the service reminder and warning lights on an M7?
Yes — the electrical and maintenance sections cover the service-reminder reset through the instrument cluster, along with the maintenance-interval schedule it ties into.
Does it include the fault/error codes for the M7-132/M7-152/M7-172?
Yes. The electrical section carries the diagnostic fault-code information plus the related sensor and ECU checks for the M7-132, M7-152 and M7-172 — not just mechanical teardown.
Are the torque specs included (wheel bolts, front axle, engine)?
Yes. The General section has the master tightening-torque tables, and each system section repeats the torques for its own fasteners (wheel bolts, front axle, engine).
Does it cover the KVT (CVT) transmission or only the powershift?
Both. The transmission section covers the 24-speed powershift (F30/R15) and the KVT continuously-variable transmission, including range service and calibration.
Which engine, and is DEF/SCR + DPF service covered?
All three use the Kubota V6108-CR-TIEF4 6.1L common-rail diesel (Tier 4 Final). The engine and emissions sections cover the DPF after-treatment and SCR/AdBlue dosing and regeneration.
