All 182 pages of this Case International 956 Operator Manual (OEM #9-12062) focus on the 956, 956XL, 1056, and 1056XL tractors: how to run them, maintain them, and keep them pulling. You get a full instruments and controls section covering the instrument cluster, PTO clutch lever, brake pedals, and differential lock, plus detailed three-point linkage procedures for draft control, remote position control, and hitching ploughs. Inside: a complete lubrication and preventative maintenance chapter with service charts, fluid capacities for every system, and interval schedules keeping your machines on spec. Set fieldwork tire inflation to 0.2 MPa and follow the cold-temperature starting procedure before you turn that key in January. Your tractor is down and the clock is running. Bookmarked and searchable, this PDF jumps you to any section in a single click.
What's Inside This Case IH 956, 956XL, 1056, 1056XL Operator Manual
| System | Pages | Key Topics |
|---|---|---|
| To the Owner of a Case International Tractor | 2 | - |
| Serial Numbers | 3-5 | General Serial Plate, Chassis Serial Number, Engine Serial Number, Transmission System Serial Number, Hydraulic System Serial Number, Mechanical Front Drive Axle Serial Number |
| Intended Use | 6-9 | - |
| Safety | 10-17 | - |
| Engine Specifications | 18-21 | Type, Firing Order, Bore, Stroke, Piston Displacement, Compression Ratio |
| General Specifications | 22-26 | Air Intake System, Cooling System, Electrical System, Battery, Alternator, Lighting |
| Travel Speeds | 27 | Field Range, Road Range, Reverse Range, Speed |
| Approximate Dimensions | 28-29 | Overall Length, Overall Width, Overall Height, Wheel Base, Ground Clearance, Turning Radius |
| Tire and Wheel Specifications | 30-35 | Tire Loads, Inflation Pressures, Maximum Load per Tire, Tread Widths, Maximum Steering Angle, Tire Size |
| Instruments and Controls | 36-53 | Instrument Cluster, Key Switch, PTO Clutch Lever, Brake Pedals, Differential Lock Pedal, Heating and Air Conditioning |
| Operating Instructions | 54-62 | Towing the Tractor, Run in Procedure, Before Starting the Engine, Normal Starting Procedure, Stopping the Engine, Cold Temperature Operation |
| Operating the Tractor | 63-81 | Before Operation, Clutch Pedal, Tow Starting the Tractor, Parking the Tractor, Differential Lock Pedal |
| Three Point Linkage Controls | 82-97 | Setting Control Lever, Mode Selector, Draft Control, Remote Position Control, Float Position, Hitching Ploughs |
| Loads Matched to Tractor | 98 | Gear Selection, Ballast, Drawbar, Hitch, Wheel Slip, Horsepower Available |
| Tractor Ballast | 99-106 | Static Weight Distribution, Front End Weights, Rear Wheel Weights, Liquid Ballast, Measuring Wheel Slip, Filling the Tires |
| Lubrication and Preventative Maintenance | 107-110 | Preventive Maintenance, Service Chart, Lubricant, Engine Hood, Radiator Grille, Side Panels |
| Engine Lubrication | 111-113 | Oil Level Check, Oil and Filter Change, Oil Type, Oil Capacity, Engine Breather Filter, Engine Oil Change |
| Transmission System Lubrication | 114-117 | Oil Level Check, Filter Element Change, Oil Type, Capacities, Suction Strainer, Oil Change |
| Hydraulic System | 118-123 | Oil Level Check, Pressure Filter Element Change, Breather Filter Element Change, Oil Type, Capacities, Auxiliary Cylinder |
| Rear Axles | 124 | Oil Level Check Interval, Breather Filter Tube Clean, Oil Change Interval, Oil Type, Capacities, Checking the Oil Level |
| Mechanical Front Drive (M.F.D.) Front Axle Lubrication | 125-131 | Steering Knuckles Grease, Universal Joints Grease, Oil Level Check, Oil Change, Capacities, Torque Check |
| Two Wheel Drive Front Axle | 132-137 | Steering Knuckles Grease, Pivot Bearings Grease, Torque Check, Check Toe in, Wheel Bearings Adjustment, Lubrication Fittings |
| Three Point Linkage Cooling System | 138-142 | - |
| "V" Belt Drives | 143-147 | Fan and Alternator Belt Tension, Fan Belt Adjustment, Alternator Belt Adjustment, Air Compressor Belt Adjustment, Refrigerant Compressor Belt Adjustment |
| Fuel System | 148-152 | Diesel Fuel, Service Intervals, Fuel Filter Element Change, Fuel Injection Pump, Fuel Filters, Fuel Feed Pump |
| Air Cleaning System | 153-156 | Dust Unloader Valve, Main Element, Safety Element, Main Element Service, Washing the Element, Safety Filter Element Service |
| Engine and PTO Clutches | 157-161 | Clutch Release Bearing Grease, Engine Clutch Adjustment, PTO Clutch Adjustment, Engine Clutch Release Bearing |
| Brakes | 162-171 | Check Oil Level, Change Brake Oil, Bleeding the Brakes, Master Brake Cylinder, Parking Brake Adjustment, Pneumatic Trailer Brake System |
| Air Conditioning System | 172 | Clean Condenser, Check Refrigerant Level, Check Compressor Drive Belt Tension |
| Tire and Rim Service | 173-174 | Checking Air Pressure, Tire Inflation Procedure |
| Electrical System | 175-182 | Checking Electrolyte Level, Filler/Breather Caps, Battery Cables and Terminals, Battery Removal and Installation, Alternator, Fuses |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| Tire Inflation Pressure (Fieldwork) | 0.2 MPa | p. 30 |
Case IH 956, 956XL, 1056, 1056XL Common Problems This Manual Covers
Case International 956 tractor experiences excessive wheel slip and poor traction during heavy fieldwork p. 30
Check the tire inflation pressures before starting operation to ensure proper ground contact. Adjust the fieldwork tire inflation pressure to exactly 0.2 MPa as detailed on page 30. Verify the front and rear wheel weights are properly distributed to prevent slippage.
Manual Section: Tire and Wheel SpecificationsLoader stops working completely and hydraulic pressure low warning light flashes on the instrument cluster p. 118
Inspect the hydraulic system oil level on page 118 to ensure it sits between the MIN and MAX marks. Replace the pressure filter element and clean the breather filter if fluid is highly contaminated. Check the auxiliary cylinder connections for visible leaks.
Manual Section: Hydraulic SystemEngine temperature gauge spikes into the red zone and coolant boils over after short operation periods p. 143
Clean the radiator grille and side panels to remove trapped debris blocking airflow. Inspect the cooling system fan belt tension as shown on page 143. Verify the engine oil level is at the FULL mark on the dipstick to prevent excess internal friction.
Manual Section: "V" Belt DrivesFrequently Asked Questions
What are the replacement specifications for Hydraulic pump?
The manual provides performance specifications for the hydraulic system, but not specific replacement part numbers for the hydraulic pump itself. For 956XL and 1056XL Sens-O-Draulic systems, the maximum operating pressure is 16 to 17 MPa (2350 to 2465 PSI). The pump output at rated engine speed is 30 Litres/min (6.6 U.K. Gallons/min), which is reduced to a constant flow of 18 (or 12) Litres/min (4 (or 2.6) U.K. Gallons/min) by the flow divider.
What are the replacement specifications for Fuel injector?
For 956/956XL models, the fuel injector nozzles are Bosch, DLLA 150 S 816 (with Pump 1) or Bosch, DLLA 150 S 836 (with Pumps 2 and 3). For 1056/1056XL models, the fuel injector nozzles are Bosch, DLLA 150 S 815 (with Pump 1) or Bosch, DLLA 150 S 836 (with Pumps 2 and 3). For both series, the nozzle holders are Bosch, KBEL 84 S 4/13, and the nozzle opening pressure is 22.5 to 23.3 MPa (3262 to 3378 PSI) with Pump 1, and 24 to 24.8 MPa (3481 to 3597 PSI) with Pumps 2 and 3.
How do you fix Case International 956 tractor experiences excessive wheel slip and poor traction during heavy fieldwork?
Check the tire inflation pressures before starting operation to ensure proper ground contact. Adjust the fieldwork tire inflation pressure to exactly 0.2 MPa as detailed on page 30. Verify the front and rear wheel weights are properly distributed to prevent slippage.
How do you fix loader stops working completely and hydraulic pressure low warning light flashes on the instrument cluster?
Inspect the hydraulic system oil level on page 118 to ensure it sits between the MIN and MAX marks. Replace the pressure filter element and clean the breather filter if fluid is highly contaminated. Check the auxiliary cylinder connections for visible leaks.
What do I get after purchasing this Case International 956, 956XL, 1056, 1056XL manual?
Immediate download of the complete 182-page searchable Operator Manual. Access it on any device, from a laptop at your desk to a phone in the field.
