Part of the Case IH Repair Manuals.
Case IH Service Manual Print No. 6-62400 covers the JX1070U, JX1080U, JX1090U and JX1100U tractors, 2WD and 4WD, with or without cab. It starts at the F4CE engine and Bosch injection pump. From there it goes through the clutch and the 12x4, reverser, Dual Command and Power Shuttle transmissions. Then come the front and rear axles, PTO, brakes, hydraulic lift with electronic draft control, steering, cab air conditioning and electrical system.
Each section opens with its data and torque tables, then fault diagnosis, then removal and overhaul. Wiring diagrams A to Z, error codes and HH menu calibrations each have their own section, so you can go straight to the page you need.
What's Inside This Case IH JX1070U, JX1080U, JX1090U, JX1100U Manual
| System | Pages | Key Topics |
|---|---|---|
| Introduction and Contents | 1-6 | Cover, Introduction, Important Warnings, Print Number and Contents of All Sections |
| General Guidelines | 7-12 | General Instructions, Safety Regulations, Consumables with Fluid Capacities and Lubricants |
| Engine | 13-140 | General Specifications, Fuel System Data, Crankshaft, Block, Piston and Cylinder Head Data, Tightening Torques, Fault Diagnosis, Disassembly and Assembly, Valve Clearance, Injectors, Bosch Injection Pump, Radiator |
| Clutch | 141-156 | LUK Clutch Data, Tightening Torques, Cross-Sectional Views, Fault Diagnosis, Pedal Adjustment, Clutch Removal, Overhaul and Release Levers |
| Transmissions | 157-272 | 12x4 Transmission and Range Gear, Reverser, Dual Command 2 Speed Power Shift with Hydraulic Diagrams, Reverser and Creeper Unit, Power Shuttle with Dual Command |
| Drive Lines | 273-292 | 4WD Electrohydraulic Engagement Data, Description and Operation, Fault Diagnosis, Services Control Valve, Drive Gear Casing |
| Front Axle Mechanical Transmission | 293-344 | Front Axle Data, Cross-Sections, Fault Diagnosis, Front Axle Removal and Overhaul, Lim-Slip Differential, Final Drive, Bevel Drive Adjustments |
| Rear Axle Mechanical Transmission | 345-402 | Bevel Drive and Differential Data, Cross-Sections, Fault Diagnosis, Gearbox Casing Removal and Overhaul, Adjustments, Side Gear Casing and Final Drive |
| Power Take-Off | 403-458 | Mechanical PTO Data and Fault Diagnosis, Electro-Hydraulic PTO with Hydraulic Diagram and Fault Diagnosis |
| Brakes | 459-482 | Brake Data, Torques, Sectional Drawings, Hydraulic Diagram of Brakes, Fault Diagnosis, Parking Brake, Air Bleeding, Brake Pump, Service Brake |
| Hydraulic Systems | 483-598 | Rear Mechanical Hydraulic Lift with Fault Diagnosis and Relief Valve Setting, Bosch Auxiliary Control Valves, Trailer Brake Valve, Supplementary Cylinder, Electronic Draft Control |
| Steering | 599-636 | Steering Data, Hydraulic Pump and Hydrostatic Control Valve, General Hydraulic Diagram, Fault Diagnosis, Control Valve Overhaul, Relief Valve Bench Testing |
| Axles and Wheels | 637-652 | Axle and Wheel Data, Front Wheel Track, Torques, Fault Diagnosis, Front Axle Hub, Stub Axle, 2WD Camber and Toe-In, 4WD Alignment |
| Cab Air Conditioning System | 653-700 | Safety, Main Specifications, Operating Principles, Components, Troubleshooting, Compressor Removal, Piping, Condenser, Dryer Filter and Heater Unit |
| Electrical System: Instruments and Components | 701-774 | Instrument Panel, Central Display, Sensors and Switches, Components, Starting System, Charging System, Battery |
| Electrical Circuits and Wiring Diagrams | 775-976 | Electrical Components, Fuses and Relays Location, Symbols, Wire Colour Coding, Connection Codes, Wiring Diagrams a to Z |
| Electrical Components Testing | 977-994 | Testing of Switches, Pressure Switches and Sensors |
| Error Codes | 995-1414 | Test Procedures and Multimeter Use, CAN System and Fault Code Display, Transmission, Rear PTO, Four Wheel Drive, Differential Lock and EDC Error Code Listings |
| HH Menu and Calibrations | 1415-1438 | HH MENU Access, Control Panel, Transmission and Advanced Keypad Calibrations |
| Bodywork and Driving Position | 1439-1474 | Bonnet Removal, Driver's Seat, Cab Removal, Door, Windows, Seals, Padding and Ceiling Fittings |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| Engine bore | 4.0944 in. (104 mm) | p. 14 |
| Engine stroke | 5.1968 in. (132 mm) | p. 14 |
| Engine displacement | 273.67 in3. (4485 cm3) | p. 14 |
| Compression ratio | 17.5:1 | p. 14 |
| Maximum power, JX1070U / JX1080U / JX1090U / JX1100U | 53 kW (70 HP) / 60 kW (80 HP) / 67 kW (90 HP) / 73,5 kW (100 HP) | p. 14 |
| Engine oil pressure, slow idling / fast idling | 17.4 psi (1.2 bar) / 55.1 psi (3.8 bar) | p. 15 |
| Valve clearance (cold), intake / exhaust | 0.30 ± 0.05 mm / 0.55 ± 0.05 mm | p. 15 |
| Injector calibration pressure | 260 to 274 bar | p. 17 |
| Injection order | 1, 3, 4, 2 (for all models) | p. 17 |
| Engine oil, without filter / with filter | 8,9 / 9,5 litres, SAE 15W--40 | p. 12 |
| Cooling system, without cab / with cab | 14 / 16 litres, 50% + 50% | p. 12 |
| Fuel tank, JX1070U, JX1080U | 105 litres | p. 12 |
| Rear transmission, lift, PTO and steering oil, JX1070U | 49 litres | p. 12 |
| Lift pressure relief valve setting | psi 2755.86 to 2828.38 (bar) (190 to 195) | p. 484 |
| Lift cylinder safety valve setting | psi 3045.95 to 3118.47 (bar) (210 to 215) | p. 484 |
| Max lifting load at link ends, category 2a | lbs. 7363.43 (3340) kg | p. 486 |
| Lift pump rated output, new pump | 48 dm3/min (l/min) | p. 487 |
| Steering relief valve setting, 4WD | psi 2393.24 to 2465.77 (bar) (165 to 170) | p. 600 |
| Power Shuttle / Dual Command gears and services working pressure | psi 227.72 to 242.22 (bar) (15.7 to 16.7) | p. 244 |
| Clutch driven plate thickness | in. 0.3779 to 0.4094 (mm) (9.6 to 10.4) | p. 142 |
| Engine speed with PTO at 540 rpm | 2200 rev/min | p. 404 |
| Service brake disk thickness / wear limit | in. (mm) 0.3937 (10) / 0.3385 (8.6) | p. 459 |
| A/C refrigerant HFC134a charge | lbs. (gr) 3.5273 (1600) | p. 655 |
| Battery capacity, JX1070U-JX1080U / JX1090U-JX1100U | 100 / 132 Ah | p. 767 |
Case IH JX1070U, JX1080U, JX1090U, JX1100U Common Problems This Manual Covers
Engine does not start
Start with the cheap causes in the Engine section's fault diagnosis table. If the batteries are partially discharged, check and recharge them. If the tank is empty, fill it. If both are fine, the table points to incorrect injection pump timing, which you adjust, or a faulty starter motor, which you repair or replace. Battery capacity is 100 Ah on the JX1070U and JX1080U and 132 Ah on the JX1090U and JX1100U.
Manual Section: Engine troubleshooting p. 33The hydraulic lift does not raise
Use the fault diagnosis table for the rear mechanical hydraulic lift in the Hydraulic Systems section. First replace a clogged oil filter. Next, check whether the control valve is jammed in release and free it. If neither fixes it, overhaul or replace the hydraulic pump. A new lift pump is rated at 48 l/min. The relief valve is set to 190 to 195 bar.
Manual Section: Hydraulic lift troubleshooting p. 498Brake pedal stroke too long
The Brakes section's fault diagnosis lists three causes. Air in the brake circuit means bleeding it, using the section's air bleeding procedure. Worn brake control pumps get replaced. Leakage from the control pipes means finding and eliminating the cause. While you're in there, check the service brake disks. They are 10 mm new, with a wear limit of 8.6 mm.
Manual Section: Brake troubleshooting p. 4654WD does not engage
Work through the fault diagnosis in the Drive Lines section for the 4WD electrohydraulic engagement. Replace the drive gear engage/disengage switch if it is faulty. Check the solenoid valve control contactor relay and replace it if necessary. Check the drive gear solenoid valve and replace it if needed. If the spring has yielded, overhaul the unit. The four wheel drive error code listing in the Error Codes section helps narrow it down.
Manual Section: Drive lines troubleshooting p. 278Frequently Asked Questions
Does this manual cover my Case IH JX1070U, JX1080U, JX1090U or JX1100U tractor?
It is Case IH Service Manual Print No. 6-62400, written for the JX1070U, JX1080U, JX1090U and JX1100U. It covers 2WD and 4WD tractors, with cab and without cab. The 12x4, reverser, Dual Command and Power Shuttle transmission versions are all included. The book prints no tractor serial number ranges. Engine versions are listed by engine type instead. p. 1
How much engine oil does a Case IH JX1070U to JX1100U take?
All four models take 8,9 litres without the filter and 9,5 litres with the filter. Use SAE 15W-40 (API CH-4, ACEA E5) or SAE 10W-30. With the engine warm, oil pressure should read 17.4 psi (1.2 bar) at slow idling. At fast idling it should read 55.1 psi (3.8 bar). p. 12
What are the Case IH JX hydraulic lift and steering relief valve settings?
The lift pressure relief valve is set to psi 2755.86 to 2828.38 (190 to 195 bar). The lift cylinder safety valve is set to psi 3045.95 to 3118.47 (210 to 215 bar). The steering relief valve setting depends on the drive version. 4WD models are set to psi 2393.24 to 2465.77 (165 to 170 bar), and 2WD models to 140 to 145 bar. p. 484
What power and torque does each Case IH JX1070U to JX1100U make?
JX1070U: 53 kW (70 HP) and 280 Nm. JX1080U: 60 kW (80 HP) and 320 Nm. JX1090U: 67 kW (90 HP) and 350 Nm. JX1100U: 73,5 kW (100 HP) and 370 Nm. Every model makes maximum power at 2500 rev/min and maximum torque at 1400 rev/min. p. 14
Does the manual include wiring diagrams, hydraulic diagrams and error codes?
Yes. The electrical section has wiring diagrams A to Z, the fuse and relay layout and the symbol key. There are hydraulic diagrams for the steering, the brakes and the tractor hydraulics with PTO. Error code listings cover the transmission, rear PTO, four wheel drive, differential lock and EDC. You also get the HH menu calibrations and a troubleshooting table in each section. p. 805
