Part of the John Deere Repair Manuals.
Need the factory numbers for your loader or tool carrier? This John Deere 624H, TC62H Repair Manual PDF (OEM TM1640) packs all 662 pages of Deere's own shop procedures for both machines, from the axle shafts to the bucket linkage. You get factory wiring diagrams for the charging system, lighting circuits, harnesses, and transmission control unit, plus a full torque-values section and step-by-step teardowns of the power shift clutch, axle reduction gears, and loader hydraulic pump. High-quality exploded views guide every reassembly. Torque the ROPS mounting bolts to 1150 N-m (850 lb-ft), then refill the hydraulic reservoir to 117 L (31 gal) before you fire it up. No more chasing electrical gremlins with a test light and a prayer. Bookmarked and keyword-searchable; pull it up on any device in the shop and get back to work.
What's Inside This John Deere 624H, TC62H Repair Manual
| System | Pages | Key Topics |
|---|---|---|
| General Information | 9-50 | Safety Information, Torque Values, Fuels and Lubricants |
| Wheels | 51-56 | Powered Wheels and Fasteners |
| Axles and Suspension Systems | 57-114 | Removal and Installation, Axle Shafts and U-Joints, Axle Shaft, Bearings, Reduction Gears, Hydraulic System |
| Transmission | 115-208 | Removal and Installation, Gears, Shafts, Bearings and Power Shift Clutch, Hydraulic System, Dealer Fabricated Tools |
| Engine | 209-220 | Removal and Installation |
| Engine Auxiliary Systems | 221-276 | Cold Weather Starting Aids, Cooling System, Speed Controls, Intake System, External Exhaust System, External Fuel Supply Systems |
| Dampener Drive | 277-280 | Elements |
| Steering System | 281-294 | Hydraulic System |
| Service Brakes | 295-306 | Brake Assembly, Brake Valve, Brake Accumulator |
| Park Brake | 307-322 | Release Solenoid Valve, Pressure Switch |
| Electrical System | 323-386 | Batteries, Alternator, Lighting System, Wiring Harness, Transmission Control Unit, Starting Motor |
| Frame or Supporting Structure | 387-406 | Loader Frame, Pivot Bearing, Fuel Tank Guard, Transmission Bottom Guard, Counterweights |
| Operator's Station | 407-492 | Cab, Windshield Wiper, Seat Belt, Steps, Heater, Air Conditioner |
| Sheet Metal and Styling | 493-506 | Hood, Engine Side Shields, Battery Covers, Grille, Fenders |
| Safety and Convenience | 507-514 | Rear View Mirror, Fire Extinguisher, Horn, Reverse Warning Alarm |
| Loader | 515-662 | Bucket, Bucket Linkage, Loader Hydraulic Pump, Loader Control Valve, Boom Cylinder, Hydraulic Reservoir |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| All Models | ||
| Engine Crankcase and Filter Capacity | 20 L (21 qt) (S.N. —582360) / 21 L (22 qt) (S.N. 582361—) | p. 24 |
| Cooling System Capacity | 22 L (23 qt) | p. 24 |
| Hydraulic Reservoir and Filters Capacity | 117 L (31 gal) | p. 24 |
| ROPS Mounting Bolts Torque | 1150 N•m (850 lb-ft) | p. 29 |
| Fuel Tank Capacity | 265 L (70 gal) | p. 45 |
| Wheel Cap Screw | 675 N•m (500 lb-ft) | p. 60 |
| Cap Screw Nut | 675 N•m (500 lb-ft) | p. 60 |
| Differential oil capacity | 25 L (26.0 qt) | p. 62 |
| Engine Power (SAE net) | 119 kW | p. 24 |
| Hydraulic Reservoir Capacity | 117 L | p. 26 |
| 624H | ||
| 624H Standard Operating Weight | 13 560 kg | p. 24 |
| TC62H | ||
| TC62H Standard Operating Weight | 13 361 kg | p. 28 |
John Deere 624H, TC62H Common Problems This Manual Covers
John Deere 624H engine cranks slowly and will not start in cold weather
Test battery state of charge and load test both batteries before winter hits. Clean and tighten cable connections at the battery and starting motor, using the Section 16 procedures starting on page 323. Review cold weather starting aids in Section 05 on page 221. If replacing the starter, support it properly; it weighs 30 kg.
Manual Section: Electrical System p. 323Loader boom drifts down and bucket responds slowly when working under full load
Check hydraulic oil level first; the reservoir and filters hold 117 L (31 gal). Inspect the loader control valve and boom cylinder seals using the procedures in Section 31, starting on page 515. Test pump flow before condemning cylinders, and replace the filters if the oil shows contamination or milkiness.
Manual Section: Loader p. 515Wheel wobble at travel speed and cap screws keep backing off after service
Torque all wheel cap screws to 675 N•m (500 lb-ft) in a star pattern, then recheck torque after the first few hours of operation. Follow the wheel removal and installation procedure on page 53, and inspect mounting faces and studs for damage, rust, or paint buildup before installing the wheel.
Manual Section: Powered Wheels and Fasteners p. 53Engine runs hot and coolant temperature gauge climbs during long grading passes
Check coolant level; the cooling system holds 22 L (23 qt). Clean chaff and debris from the radiator core and check fan belt tension. Pressure test the cap and hoses, then work through the cooling system procedures in Section 05, beginning on page 221, before replacing the thermostat or water pump.
Manual Section: Engine Auxiliary Systems p. 221Differential howls at road speed and axle oil leaks around the hubs
Drain the differential and inspect the oil for metal flake; refill capacity is 25 L (26.0 qt) per the spec on page 62. Use the exploded parts view to locate hub seals and bearings. Replace leaking seals in pairs and check bearing preload before final assembly.
Manual Section: Axles and Suspension Systems p. 62Frequently Asked Questions
What are the recommended service intervals for the service brakes?
The service brakes should undergo their first inspection at 5000 hours of operation. Following this initial check, subsequent inspections should be performed at 1000-hour intervals. p. 297
What is the fuel tank capacity for the 624H and TC62H models?
The fuel tank capacity for both the 624H Loader and the TC62H Tool Carrier is 265 liters (70 gallons). p. 26
What is the torque specification for the ROPS mounting bolts?
When installing equipment that requires the removal or loosening of the ROPS, the mounting bolts must be tightened to a torque of 1150 N•m (850 lb-ft). p. 31
What is the procedure for checking the oil level in the differential housing?
To properly check the oil level, do not thread the dipstick into the port. Allow 10 minutes for the oil to stabilize in each sump before checking the level. p. 65
What is the torque specification for the wheel cap screws on the 624H and TC62H?
The wheel cap screws must be tightened to a torque of 675 N•m (500 lb-ft). p. 53
Is this John Deere 624H, TC62H Repair Manual a digital download?
Immediate download of the complete 662-page searchable Repair Manual. Access it on any device, from a laptop at your desk to a phone in the field.
Am I able to print pages from this John Deere 624H, TC62H manual?
Absolutely. No DRM or copy protection. Print the whole manual or just the pages you need. Any home or office printer works.
