Need the factory operator guide for your Case IH Maxxum 140? This 432-page operator manual (OEM #47897129) puts the complete Maxxum family in one place: 110, 115, 120, 125, 130, and 140 tractors, from cab access and instrument cluster through field operations and daily upkeep. Open to the controls section and you get a full walkthrough of every switch, lever, and dashboard indicator on your platform. Inside: a working operations block covering variable engine power management, PTO, and transmission settings, plus maintenance intervals, fluid capacities, a troubleshooting guide, and error codes. Confirm engine oil at 15 L (6-cylinder) or 10 L (4-cylinder), DEF/AdBlue at 37 L, and fuel to 227 L on 6-cylinder models before startup. Your tractor's parked. Grab your tablet, jump to any bookmarked section, and get back in the seat.
What's Inside This Case IH Maxxum 110-140 Operator Manual
| System | Pages | Key Topics |
|---|---|---|
| General Information | 11-20 | Metric and Imperial Units Abbreviations, To the Owner, Product Identification, Engine Identification, Drive Line Identification, Cab Identification, Ecology and the Environment |
| Safety Information | 31-60 | Safety Precautions, Safety Decals, Safety Rules, Burn Prevention, Prevention of Fire or Explosions, Hazardous Substances |
| Controls and Instruments | 61-136 | Access to Operator's Platform, Operator's Seat, Forward Controls, Right-Hand Side Controls, Rearward Controls, Instrument Cluster |
| Operating Instructions | 137-148 | Commissioning the Unit, Starting the Unit, Stopping the Unit, Moving the Unit |
| Transport Operations | 149-152 | Carrying the Tractor on a Transporter, Secure the High Visibility Roof Panel, Freeing a Stuck Tractor, Towing the Tractor |
| Working Operations | 153-300 | Variable Engine Power Management, Transmission, Rear Power Take- |
| Maintenance | 301-386 | - |
| Troubleshooting | 387-394 | - |
| Specifications | 395-416 | - |
| Accessories | 417-422 | Radio, External Rear View Mirrors, Auxiliary Headlights, Rotating Beacon, Front-End Loader Fixation Points |
| Forms and Declarations | 423-426 | - |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| 4 Cylinder models | ||
| Fuel tank capacity | 175 l (46.2 US gal) | p. 313 |
| Engine oil capacity (including filter) | 10 l (2.64 US gal) | p. 313 |
| Engine Displacement | 4485 cm³ (274 in³) | p. 402 |
| 6 Cylinder models | ||
| Fuel tank capacity | 227 l (60.0 US gal) | p. 313 |
| Engine oil capacity (including filter) | 15 l (3.96 US gal) | p. 313 |
| Engine Displacement | 6728 cm³ (411 in³) | p. 402 |
| All Models | ||
| DEF/AdBlue® tank capacity | 37 l (9.8 US gal) | p. 313 |
| Transmission/rear axle/hydraulics capacity (16x16) | 62 l (16.4 US gal) | p. 313 |
| Transmission/rear axle/hydraulics capacity (24x24) | 65.5 l (17.3 US gal) | p. 313 |
| Front PTO capacity | 0.5 l (0.13 US gal) | p. 313 |
| Rear wheel disc to hub nuts torque | 250 Nm (184 lb ft) | p. 334 |
| Radiator pressure cap | 1 bar (14.5 psi) | p. 403 |
Case IH Maxxum 110-140 Common Problems This Manual Covers
Case IH Maxxum 110 transmission power loss or slipping during semi-power shift operation under heavy load p. 388
Check the transmission error codes on page 388. Verify the 16x16 transmission fluid level and ensure the system is filled to its 62 l (16.4 US gal) capacity as listed on page 313. Inspect the hydraulic filters for blockage if an E02 code is active.
Manual Section: TroubleshootingInstrumentation warning light flashing for low DEF level or power limitation active during normal field operation p. 313
Inspect the DEF tank and fill it to the 37 l (9.8 US gal) capacity shown on page 313. Verify the fluid quality is correct for the emissions system. Drain and clean the tank if you suspect contaminated fluid to clear the injection failure warning.
Manual Section: MaintenanceEngine overheating indicator illuminated and coolant loss noticed around the radiator area after heavy draft work p. 403
Inspect the radiator pressure cap on page 403 and verify it holds the specified 1 bar (14.5 psi) of pressure. Clean all accumulated dust and field debris from the front grille and cooling package. Check the coolant level in the expansion tank before restarting the tractor.
Manual Section: SpecificationsClunking noise from the rear axle area when turning or operating with heavy three-point hitch implements p. 334
Check the rear wheel disc to hub nuts and tighten them to 250 Nm (184 lb ft) as specified on page 334. Inspect the wheel weights for loose mounting hardware. Verify the rear tire pressure matches the implement load before returning to the field.
Manual Section: MaintenanceHydraulic system failure preventing implement operation or slow response from the multicontroller remote valve levers p. 387
Review the troubleshooting procedures on page 387 for hydraulic systems not operating. Check the rear sight glass and add fluid if the 62 l (16.4 US gal) reservoir is low. Inspect the remote couplers for dirt or damaged seals before attaching any implement hoses.
Manual Section: TroubleshootingFrequently Asked Questions
How to reset the error code on CASE IH Maxxum 110-140 tractors?
For DEF/AdBlue® storage tank fluid level faults, the system can be reset by raising the tank level above 15% total volume and cycling the key switch to OFF or returning the throttle to low idle. For technical faults, the component causing the fault must be repaired or replaced, and switching off the engine will reset the system, allowing it to restart at full power. If the same failure is re-detected within 40 hours of engine operation, the last active engine power loss level will be activated.
How to reset the service interval counter on CASE IH Maxxum 130 after 750-hour oil change?
To reset the service reminder, access the SETUP MENU in the Dot Matrix Display by depressing and holding the Menu/Enter key. Scroll to the service reminder symbol, select the set-up screen, and then re-set the Service Reminder interval to zero or change the period until the next service is due. The manual's maintenance chart lists engine oil and filter changes at 600 hours, not 750 hours.
How do you fix case IH Maxxum 110 transmission power loss or slipping during semi-power shift operation under heavy load?
Check the transmission error codes on page 388. Verify the 16x16 transmission fluid level and ensure the system is filled to its 62 l (16.4 US gal) capacity as listed on page 313. Inspect the hydraulic filters for blockage if an E02 code is active.
How do you fix instrumentation warning light flashing for low DEF level or power limitation active during normal field operation?
Inspect the DEF tank and fill it to the 37 l (9.8 US gal) capacity shown on page 313. Verify the fluid quality is correct for the emissions system. Drain and clean the tank if you suspect contaminated fluid to clear the injection failure warning.
Is this Case IH Maxxum 110 & variants Operator Manual a digital download?
A 432-page Operator Manual in searchable PDF format, available the moment you complete checkout. View on computer, tablet, or phone, with no shipping wait.
Can I print this manual?
Yes, print as many copies as you want, and there are no restrictions. Many mechanics print the section they need and bring it to the shop floor.
