Your daily operations run smoother when you keep this 148-page JCB Fastrac 3155, 3185 operator manual pdf loaded on your device. Inside, you get a full breakdown of dashboard instruments, visual warning indicators, system error codes, and step-by-step operating procedures for the electronic linkage control. Packed with exact factory maintenance schedules, it shows you how to handle routine greasing, air brake connections, and front PTO attachments without second-guessing the correct process. Swap the hydraulic filter element every 250 operating hours and tighten the 3155 engine oil drain plug to exactly 34 Nm before refilling the system. Guesswork leads to blown schedules and broken equipment. Download this bookmarked file straight to your tablet, jump directly to the fluid capacities section, and keep your machine in the dirt where it belongs.
What's Inside This JCB Fastrac 3155, 3185 Operator Manual
| System | Pages | Key Topics |
|---|---|---|
| Introduction | 3-28 | About This Handbook, The JCB Fastrac, Safety First, Safety Decals, Identifying Your Machine |
| Operation | 29-98 | Introduction, Entering/Leaving the Cab, Cab Layout and Controls, Instrument Cluster, Switches, Air Conditioning and Heater Controls, Seats, Seat Belts |
| Moving a Disabled Machine | 99-101 | General, Preparation for Towing, Removing the Propshafts |
| Transporting the Machine | 102-110 | Trailer, Parking Brake, Engine, Cab, Drawbar, Trailer Axle |
| Maintenance | 111-148 | Service Requirements, Service Schedules, Lubricants - Health and Safety, Fluids, Lubricants Capacities and Specifications (Fastrac: 3155, 3185), Cleaning the Machine |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| Fastrac 3155 | ||
| Engine oil drain plug torque | 34 Nm (25 lb ft) | p. 130 |
| Fan belt slack (Fastrac 3155) | 10 mm (0.4 in) | p. 136 |
| Fastrac 3185 | ||
| Engine oil drain plug torque | 30 Nm (59 lb ft) | p. 131 |
| Fan belt adjustment bolt G torque | 43 Nm (32 lbf ft) | p. 137 |
| All Models | ||
| Hydraulic filter element replacement interval | Every 250 Operating Hours or 3 Monthly | p. 112 |
| Hydraulic tank suction strainers replacement interval | Every 2000 Operating Hours or 2 Years | p. 114 |
| Engine oil and filter(s) replacement interval | Every 250 Operating Hours or 3 Monthly | p. 112 |
| Fuel filter replacement interval | Every 50 Operating Hours or Weekly | p. 112 |
| Air filter element replacement interval | Every 250 Operating Hours or 3 Monthly | p. 112 |
| Inner air filter element replacement interval | Every 2000 Operating Hours or 2 Years | p. 114 |
| Foot brake pad thickness for replacement | 3 mm (0.12 in) or less | p. 126 |
| Parking brake pad thickness for replacement | 3 mm (0.12 in) or less | p. 127 |
JCB Fastrac 3155, 3185 Common Problems This Manual Covers
JCB Fastrac 3155 and 3185 brake pedal feels spongy or stopping distance increases noticeably during field operation p. 126
Inspect the foot brake fluid level and check the pads. Replace the foot brake pads if friction material thickness reaches 3 mm (0.12 in) or less, as detailed on page 126. Drain and replace the brake system fluid every 2000 operating hours to prevent moisture buildup.
Manual Section: Brakes - Checks and WearEngine coolant temperature gauge spikes into the red zone while pulling heavy implements p. 136
Check the coolant level in the expansion tank and clean any debris from the radiator fins. Verify the fan belt slack is exactly 10 mm (0.4 in) on the 3155 model as noted on page 136. Drain and replace the engine coolant every 2000 operating hours.
Manual Section: Engine Cooling System - Overheating/Low CoolantLow engine oil pressure warning light illuminates on the dashboard immediately after startup p. 117
Verify the engine oil level using the dipstick. When changing the oil on the 3185 model, refill the crankcase with exactly 15 Litres (3.3 UK Gal) of approved oil as specified on page 117. Torque the drain plug to 30 Nm (59 lb ft) according to page 131.
Manual Section: Engine Oil - Level and FilterHydraulic implement lift operates slowly or intermittently stops working during continuous heavy loader cycles p. 113
Check the hydraulic fluid level sight glass to ensure it is at the correct mark. Replace the hydraulic fluid filter element every 500 operating hours or six months as shown on page 113. Top up the system using the correct grade fluid if the level drops.
Manual Section: Hydraulic System - Fluid LevelFrequently Asked Questions
What do JCB Fastrac error codes mean?
JCB Fastrac error codes are displayed on the centre display 30, accompanied by the flashing of the 'book' icon (item 17). The error information alternates with basic data and begins with 'Number of errors in the system is X ERRORS'. Specific codes like T010-T018 indicate Powershift faults, T060-T063 signify Transmission speed trigger faults, and T100-T126 denote Clutch control faults. The manual provides a detailed list of codes and their corresponding meanings.
What are the replacement specifications for hydraulic filters?
The hydraulic fluid filter element should be replaced every 250 operating hours or 3 monthly, whichever occurs first. The manual advises using JCB Genuine Parts for replacements. Specific part numbers or detailed filter types are not provided, but the service schedule clearly outlines the replacement interval.
How do you fix JCB Fastrac 3155 and 3185 brake pedal feels spongy or stopping distance increases noticeably during field operation?
Inspect the foot brake fluid level and check the pads. Replace the foot brake pads if friction material thickness reaches 3 mm (0.12 in) or less, as detailed on page 126. Drain and replace the brake system fluid every 2000 operating hours to prevent moisture buildup.
How do you fix engine coolant temperature gauge spikes into the red zone while pulling heavy implements?
Check the coolant level in the expansion tank and clean any debris from the radiator fins. Verify the fan belt slack is exactly 10 mm (0.4 in) on the 3155 model as noted on page 136. Drain and replace the engine coolant every 2000 operating hours.
How quickly can I access this manual after buying?
You get a 148-page searchable PDF that downloads instantly after checkout. Open it on your laptop, tablet, or phone, and bring it right to the shop floor.
Am I able to print pages from this manual?
Yes. The PDF has no DRM restrictions, so print any page or section you need for your shop. Works with any standard printer.
Document Quality
This document is a high-quality, native digital PDF, allowing you to search and copy the full text content. All text is crisp and clear, ensuring easy readability throughout. Diagrams and illustrations are primarily raster images, but they are consistently clear with readable labels, even when zoomed in. The pages are clean, free from scan artifacts, stains, or skewed content. There is one blank page (page 2) which serves as a filler page.
