Power Shift transmission diagnosis is the toughest chapter in TM1550, and it sits inside an 803-page John Deere 8770 operation and test manual PDF that covers four 4WD tractors in the 8570 through 8970 family. Electrical operation and tests fill more than a quarter of the book, with wiring diagrams that trace the starting and charging circuits through the load center, fuses, relays and connectors. Hydraulic schematics back the three-point hitch diagnosis and system tests in a section taking over a fifth of the pages, while separate chapters handle the 12-Speed Syncro and 24-Speed Powrsync gearboxes, PTO, axles, differentials, steering, brakes and cab air quality. Confirm your Nippondenso alternator puts out 120 amps, and expect an 8770 to make 256 hp at 2100 rpm. Every day that tractor sits is a day of field work gone. Bookmarks and a searchable text layer put you on the right test in seconds, so the tractor goes back to the field before the weather turns.
What's Inside This John Deere 8570, 8770, 8870, 8970 Manual
| System | Pages | Key Topics |
|---|---|---|
| General Information | 8-61 | Safety, Machine Operational Checks, General Reference Information, Test Equipment Calibration |
| Engine Operation and Tests | 62-87 | System Diagnosis, Theory of Operation |
| Fuel and Air Operation and Tests | 88-99 | Air Intake System, Diesel Fuel System |
| Electrical Operation and Tests | 100-321 | Electrical System Introduction, Load Center, Fuses, Relays and Connectors, Preliminary Checks, Operational Checks, Starting Circuit, Charging Circuit |
| Syncro 12-Speed & Powrsync 24-Speed Transmission | 322-397 | Operational Checks, Transmission System Diagnosis, Theory of Operation |
| Power Shift Transmission | 398-517 | Power Shift Transmission System Diagnosis, Power Shift Theory of Operation |
| PTO, Axles and Differentials | 518-533 | Theory of Operation |
| Steering and Brakes | 534-555 | Operational Checks, System Diagnosis, Steering and Brake Tests, Theory of Operation |
| Hydraulic System | 556-737 | Operational Checks, Hydraulic System Diagnosis, Hitch System Diagnosis, Tests, Theory of Operation, Hitch System Theory of Operation |
| Operator Station | 738-783 | Air Quality System Operational Checks, Air Quality System Diagnosis, Theory of Operation, Seat Diagnosis |
| Dealer Fabricated Tools | 784-799 | Fabricated Tools |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| 8570 | ||
| 8570 Power Rating | 205 hp at 2100 rpm | p. 64 |
| 8770 | ||
| 8770 Power Rating | 256 hp at 2100 rpm | p. 64 |
| 8870 | ||
| 8870 Power Rating | 298 hp at 2100 rpm | p. 64 |
| 8970 | ||
| 8970 Power Rating | 339 hp at 2100 rpm | p. 64 |
| All Models | ||
| Nippondenso Alternator Output | 120 amps | p. 110 |
John Deere 8570, 8770, 8870, 8970 Common Problems This Manual Covers
Electro-hydraulic three-point hitch throwing hitch fault codes or raising slowly under load
Read the hitch fault codes and work through the electro-hydraulic hitch circuit checks in Hitch System Diagnosis, part of the Hydraulic System section on page 556. Test hitch valve flow, then check the hitch cylinder for a piston packing leak. Run the hitch operational check afterward, before you hook back up and head to the field.
Manual Section: Hitch System Diagnosis p. 556Power Shift PTO clutch not engaging cleanly or low transmission system pressure
Measure transmission system pressure and check clutch element modulation using the Power Shift Transmission System Diagnosis beginning on page 398. Test transmission pump flow, then go through the PTO clutch/brake checks. On 12-Speed Syncro or 24-Speed Powrsync tractors, use the transmission diagnosis in the section starting on page 322 instead.
Manual Section: Power Shift Transmission System Diagnosis p. 398Engine ECU logging diagnostic codes, viscous fan drive not engaging during field work
Pull the ECU diagnostic codes and look up each one in the Error Code Reference on page 83. Follow the engine diagnosis steps in Engine Operation and Tests before you swap any sensors, and check the viscous fan drive while you are in there. Clear the codes, rerun the engine running operational check, then confirm nothing comes back.
Manual Section: Engine Operation and Tests p. 83Frequently Asked Questions
How do I clear stored diagnostic codes on a John Deere 8970 tractor?
On the 8970, stored engine codes show as flash codes on the Engine Electronics Lamp: stop the engine, turn the key to ON and press the button on the Field/Cruise Module under the right-hand console (page 84). To clear them, use Clear Codes Mode on the INTELLITRAK tachometer module: momentarily switch the field lights while "dSP inFo" is displayed, step the right turn signal to the ECU designator (or ALL), then turn the field lights on until "CLr donE" appears (page 213). p. 84
How do you fix john Deere 8970 4WD starting circuit fault, engine will not crank or starts only intermittently?
Check the fuses and relays at the load center first, then work through the starting circuit diagnosis in the Electrical Operation and Tests section beginning on page 100. Inspect the connectors for corrosion and loose pins before you condemn any parts. Run the starting operational check so you know the fault is real before pulling anything. p. 100
How do you fix charging circuit fault on the tractor, Nippondenso alternator output suspected below its rated amperage?
Test the charging circuit and check alternator output against the 120 amps rating listed on page 110. Verify the fuses, relays and connectors in the charging circuit before you replace the alternator. A loose connector costs you an afternoon; a new alternator costs a lot more and still leaves you parked if the wiring was the fault. p. 110
How do you fix remote hydraulics SCV malfunction with weak main hydraulic pump output and slow implement response?
Test main hydraulic pump performance following the Hydraulic System Diagnosis procedures in the section starting on page 556. Check for axle-PTO leakage and transmission filter restriction before you blame the pump, then narrow it down to the SCV that is acting up. Calibrate your test equipment first so your readings actually mean something. p. 556
What exactly do I receive with this John Deere 8570 Operation and Test Manual?
Delivery is instant: a 803-page searchable PDF is yours the second checkout clears. Laptop, tablet, or phone, all fine.
Is this John Deere 8570 Operation and Test Manual printable?
Zero restrictions. The PDF is DRM-free. Print whatever sections you need to take out to the shop. Standard letter or A4 paper works.
Is there a hydraulic diagram in this John Deere 8570 Operation and Test Manual?
Included. Hydraulic system schematics cover all circuits, control valves, and component specifications for the John Deere 8570, 8770, 8870, 8970. You can see one on page 386.
