Gasoline and diesel builds of the John Deere 1000 and 1010 crawler tractor split at the engine, and this 448-page John Deere 1000, 1010 service manual PDF (John Deere SM2034) settles which procedure belongs to your machine. Wiring diagrams trace the diesel lighting and starting circuits and the gasoline ignition side terminal by terminal. The Hydraulic Direction Reverser takes one of the longest chapters in the book, schematics included, while the Series 10 Winch, final drives, steering clutches and brakes, and the 3-Point Hitch and drawbar each carry their own teardown sequences and trouble shooting charts. Set steering lever free travel at 7/8 to 1 inch at the starter switch, and check the clutch pressure spring at 141 to 157 pounds at a height of 1-11/16 inches. Guessing costs you a second teardown, or a reverser bought twice. Bookmarked and text-searchable, it prints clean, so the pages can ride out to the field and take grease.
What's Inside This John Deere 1010, 1000 Manual
| System | Pages | Key Topics |
|---|---|---|
| Description, Operation, and Specifications | 5-18 | Operation, Specifications |
| Periodic Lubrication | 19-32 | Lubrication Timetable, Detailed Periodic Services |
| Engine Tune-Up and Tractor Adjustment | 33-50 | Purpose of Tune-Up and Adjustment, Engine Tune-Up, Tractor Adjustment |
| Engine (Basic), Gasoline | 51-86 | Engine Removal and Installation, Cylinder Head, Manifold, And Muffler, Pistons and Connecting Rods, Crankshaft, Main Bearings |
| Engine (Basic), Diesel | 87-122 | Engine Removal and Installation, Cylinder Head, Manifold, And Muffler, Pistons and Connecting Rods, Crankshaft, Main Bearings |
| Engine Lubrication System | 123-132 | Oil Pump, Oil Filter |
| Governor and Linkage | 133-152 | Governor (John Deere), Governor (Pierce), Speed Control Linkage (Gasoline), Speed Control Linkage (Diesel) |
| Cooling System | 153-164 | Description and Servicing, Radiator, Pressure Cap, And Fan Assembly, Water Pump, Thermostat, And Water Manifold |
| Gasoline Fuel System | 165-182 | Carburetor, Fuel Tank and Fuel Filter, Oil Bath Type Air Cleaner, Dry Type Air Cleaner |
| Diesel Fuel System | 183-202 | Description and Fuel Specifications, Fuel Tank, Fuel Strainer and Fuel Filters, Fuel Injection Pump, Injector Nozzles, Turbulence Chambers, Oil Bath Type Air Cleaner |
| Electrical System | 203-234 | Distributor, Coil, Spark Plugs, And Glow Plugs, Battery, Lighting and Starting System (Diesel), Lighting and Ignition System (Gasoline) |
| Engine Clutch | 235-242 | Clutch Assembly, Clutch Controls and Clutch Housing |
| Transmission and Ring Gear | 243-282 | Description and Operation, Shifter Mechanism, Transmission Rear Cover, Output Shaft and Ring Gear and Hub Assembly, Transmission Input Shaft, Powershaft and Transmission Case |
| Hydraulic Direction Reverser | 283-324 | Description and Operation, Removal and Installation, Servicing |
| Power Take-Off and Belt Pulley | 325-332 | Power Take-Off, Belt Pulley |
| Series 10 Winch | 333-364 | Servicing the Winch Assembly, Winch Hydraulic Control and Accumulator, Winch Fairlead Assembly, Trouble Shooting and Specifications |
| Final Drives, Steering Clutch, and Brakes | 365-398 | Description and Adjustment, Final Drive, Steering Clutch and Brake, Steering Clutch Pressure Plate |
| Hydraulic System | 399-410 | Hydraulic Pump, Hydraulic Lines and Reservoir |
| Point Hitch, Timber Hitch and Drawbar | 411-420 | Universal 3-Point Hitch, Timber Hitch, Drawbar |
| Track System | 421-440 | Description and Adjustment, Tracks, Track Carrier Assemblies |
| Sheet Metal and Protective Equipment | 441-442 | Hood and Grille |
| Trouble Shooting | 443-448 | Hydraulic Pump |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| 1010 Diesel | ||
| Diesel engine maximum torque | 100 ft-lbs | p. 6 |
| Diesel Engine Slow Idle Speed | 750 rpm | p. 12 |
| Diesel Engine Fast Idle Speed | 2650 rpm | p. 12 |
| All Models | ||
| Crankshaft rear oil seal plate attaching screws torque | 16 - 18 ft-lb | p. 121 |
| Pressure spring check | 141-157 pounds at a height of 1-11/16-inches | p. 236 |
| Filter cover-to-reverser case mounting hardware torque | 35 ft-lbs. | p. 323 |
| Steering Lever Free Travel at Starter Switch Level | 7/8 to 1 Inch | p. 397 |
| Cylinder Head Bolt Torque | 150 ft-lbs | p. 39 |
| Generator Belt Tension | 5/8-inch flex at 25 pounds pull | p. 36 |
| 1010 Gasoline | ||
| Gasoline Engine Slow Idle Speed | 600 rpm | p. 10 |
| Gasoline Engine Fast Idle Speed | 2700 rpm | p. 10 |
| Gasoline | ||
| Spark Plug Gap | .025 inch | p. 35 |
John Deere 1010, 1000 Common Problems This Manual Covers
John Deere 1010 crawler drifts left when driving straight, steering clutch won't release
Check steering lever free travel before you pull anything apart. Measure at the starter switch level: each lever needs 7/8 to 1 inch, per page 397. If the left lever runs short, adjust it to match, then work both pedals loose with penetrating oil and fresh grease.
Manual Section: Final Drives, Steering Clutch, and Brakes p. 397Dozer blade will not lift or drifts down slowly with the lever held back
Check reservoir level cold, then cycle the lever full stroke and watch for a lazy drop. Bring a 1010 diesel to its 2650 rpm fast idle listed on page 12 and listen at the pump inlet. Clean the suction screen, replace softened hose, and trace the circuit on the schematic on page 408.
Manual Section: Hydraulic System p. 399Runs hot and the direction reverser gets warm after ten minutes of light work
Drain the reverser and change the oil filter first, torquing the filter cover hardware to 35 ft-lbs on page 323. Then run the relief valve pre-test: pressure should come up to 100 psi (page 291). Low or sluggish pressure means worn pump or a stuck valve. Fix it in the shop, not in the field.
Manual Section: Hydraulic Direction Reverser p. 291Engine loses power under load, stumbles and smokes when the governor opens up
Pull the air cleaner and service it before you chase fuel. On a gasoline tractor, gap plugs to .025 inch per page 35, then set slow idle at 600 rpm and fast idle at 2700 rpm. Check the fuel strainer and return line for restriction before touching the carburetor.
Manual Section: Engine Tune-Up and Tractor Adjustment p. 35Clutch slips under load and pedal feels soft pulling a loaded drawbar
Measure pedal free travel and inspect the pressure springs while the clutch is out. Each spring should test 141 to 157 pounds at a height of 1-11/16 inches, per page 236. Replace any weak spring as a set, check the facings for oil, and adjust the linkage before harvest.
Manual Section: Engine Clutch p. 236Frequently Asked Questions
How do you adjust the clutch on a John Deere 1010?
To adjust the clutch pedal free travel, loosen the jam nut on the control lever set screw in front of the pedal. Measure the free travel at the pedal pad and screw the set screw in or out until 1-3/8 inches of free travel is obtained. Tighten the jam nut on the set screw and recheck the travel. p. 47
What is the torque specification for the cylinder head bolts on a John Deere 1010?
The cylinder head bolts should be torqued to 150 ft-lbs. This should be done in the specific sequence shown in the manual for either the gasoline or diesel engine. p. 62
What is the correct engine oil pressure for the John Deere 1010?
The engine oil pressure should be between 35 and 50 pounds per square inch (psi) when the engine is running at operating speed. p. 6
What is the correct valve clearance for the gasoline engine on a John Deere 1010?
When the engine is cold, the intake valves should be set to .012-inch and the exhaust valves should be set to .018-inch. p. 63
What is the correct spark plug gap for the gasoline engine in a John Deere 1010, 1000 crawler tractor?
The spark plug electrode gap should be set to .025 inch. p. 35
What do I get after purchasing this John Deere 1000 manual?
Straight to your device: 448 pages of searchable Service Manual, downloadable the moment payment goes through.
