Three hundred ninety-eight pages stand between you and a skid steer that quits mid-shift, because TM2151 is the John Deere 317, 320, CT322 OPERATION AND TEST MANUAL written to get the 317 and 320 skid steers and the CT322 compact track loader running again without a dealer visit. Harness diagrams trace the engine, cab, and front chassis runs circuit by circuit, down to the back-up alarm and Electric Quik-Tatch wiring. Hydraulic and hydrostatic theory, diagnostics, and tests take up more than a third of the book, with diagnostic trouble code tables you can read straight off the monitor unit. Check boom drift, then measure the boom spool lock solenoid (Y2): 14.8 to 18.2 ohms, and confirm fast idle lands between 2930 and 3070 rpm. Some nights it is you, the machine, and nobody to call. Bookmarked and text searchable, this download is yours once you buy it, for as long as you own the loader.
Complete the set for your 317, 320, CT322
What's Inside This John Deere 317, 320, CT322 Manual
| System | Pages | Key Topics |
|---|---|---|
| General Information | 5-20 | Safety (Recognize Safety Information, Follow Safety Instructions, Operate Only If Qualified, Wear Protective Equipment, Avoid Unauthorized Machine Modifications, Inspect Machine, Stay Clear of Moving Parts, Avoid High-Pressure Oils, Beware of Exhaust Fumes, Prevent Fires, Prevent Battery Explosions, Handle Chemical Products Safely, Dispose of Waste Properly, Prepare for Emergencies, Use Steps and Handholds Correctly, Start Only From Operator's Seat, Use and Maintain Seat Belt, Prevent Unintended Machine Movement, Avoid Work Site Hazards, Keep Riders Off Machine, Avoid Backover Accidents, Avoid Machine Tip Over, Operating or Traveling on Public Roads, Add and Operate Attachments Safely, Park and Prepare for Service Safely, Service Cooling System Safely, Remove Paint Before Welding or Heating, Make Welding Repairs Safely, Drive Metal Pins Safely) |
| Operational Checkout Procedure | 21-35 | Diagnostic Trouble Codes, Monitor and Gauge Circuits, Hydraulic Control Enable, Park Brake, Boom and Bucket Drift, Heating and Air Conditioning |
| Engine | 36-43 | Theory of Operation, Diagnose Observable Machine Symptoms, Tests |
| System Information | 44-53 | Electrical Diagram Information, Schematic Symbols, Continuity Charts |
| System Diagrams - Fuses and Harnesses | 54-75 | Fuse Specifications, Engine Harness, Cab Harness, Front Chassis Harness |
| System Diagrams - Specialized Harnesses | 76-129 | Back-Up Alarm Harness, Dual Flasher Harness, Horn Harness, Air Conditioner and Heater Harness, Wiper Harness, Auxiliary Power Harness |
| Sub-System Diagnostics | 130-139 | Starting Circuit Theory, Engagement and Monitor Unit Circuit, Back-Up Alarm Circuit, Electric Quik-Tatch Theory |
| References - Engagement and Monitor Unit | 140-192 | Anti-Theft Security System, Diagnostic Trouble Codes, Engagement and Monitor Unit Operation, Data Items |
| References - Electrical Components and Testing | 193-222 | Diagnostic Trouble Codes, Electrical Component Specifications, Fuse Test, Relay Test, Alternator Test, Solenoid Test, Connector Repair |
| Power Train | 223-237 | Theory of Operation, Diagnostic Information, Tests |
| Hydraulic System | 238-326 | Theory of Operation, Diagnostic Information, Tests |
| Hydrostatic System | 327-381 | Theory of Operation, Diagnostic Information, Tests |
| Heating and Air Conditioning | 382-398 | Theory of Operation, Diagnostic Information, Tests |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| All Models | ||
| Engine—Slow Idle Speed | 1230—1370 rpm | p. 40 |
| Engine—Fast Idle Speed | 2930—3070 rpm | p. 40 |
| Boom Spool Lock Solenoid (Y2) Resistance | 14.8-18.2 Ohms | p. 196 |
| Bucket Spool Lock Solenoid (Y3) Resistance | 14.8-18.2 Ohms | p. 196 |
| High Flow Solenoid (Y7) Resistance | 5.7-10.6 Ohms | p. 196 |
| Refrigerant Leak Detector Probe Speed | 25 mm per second, 1 in. per second | p. 392 |
| Boom Cylinder Drift | 12.7 mm Maximum | p. 29 |
| System Relief Pressure | 23 800 kPa | p. 306 |
| Charge Pressure Relief Valve Pressure | 1900 kPa | p. 310 |
| CT322 | ||
| Two Speed Solenoid (Y6) Resistance | 7-10.5 Ohms | p. 196 |
| 317 | ||
| 317 Turbocharger Boost Pressure | 110 kPa at 2800 rpm | p. 42 |
| 320/CT322 | ||
| 320/CT322 Turbocharger Boost Pressure | 121 kPa at 2800 rpm | p. 42 |
