Need the factory numbers for your John Deere 355D? This 403-page John Deere 355D Technical Manual PDF (OEM #TM1771) covers the diesel lawn and garden tractor from engine to mower deck. Inside: full wiring harness schematics with circuit-by-circuit operation (power, start, charging, PTO), hydraulic lift system diagrams, and step-by-step repair procedures for the hydrostatic transaxle, steering valve, brakes, and the 38, 44, 48, and 54-inch mower decks. You also get spec tables for metric and inch fasteners, O-ring fittings, lubricants, and coolant. Fill the crankcase with 2.27L of oil when you swap the filter, and confirm the battery still cranks at 500 cold cranking amps before you blame the starter. No more chasing wiring faults with a multimeter and a prayer. Bookmarked PDF with a live text layer; jump to any section or search a spec by keyword and get back to wrenching.
What's Inside This John Deere 355D Manual
| System | Pages | Key Topics |
|---|---|---|
| Vehicle and Engine Specifications | 11 | Vehicle Specifications, Engine (Cylinder Bore, Stroke, Compression Ratio, Slow Idle), Fuel System, Cylinder Bore, Slow Idle, Lubrication System, Cooling System |
| Electrical Specifications | 12 | Ignition System, Starter Solenoid, Charging System, Battery Capacity, Headlights, Ignition Interlock Switches |
| Hydraulics Specifications | 13-14 | Lift System, Lift Control Valve, Cutting Unit Lift, Hydraulic Filter |
| Break-In Engine Oil | 15 | Api Service Classification, Ccmc Specification |
| Hydrostatic Transmission and Hydraulic Oil | 16 | Low Viscosity Hy-Gard Oil, Jdm J20D Standard, Jdm J20C Standard, Ccmc Specifications, Api Service Classifications |
| Alternative Lubricants | 17 | Alternative Lubricant Recommendations, Factory Fill, Synthetic Lubricants |
| Gasoline Engine Coolant | 18 | Pre-Diluted Anti-Freeze, Coolant Concentrate, Ethylene Glycol Base Coolant, Astm Specifications |
| Machine Identification Number | 19 | Engine Serial Number, Carburetor Serial Number, Hydrostatic Transmission Serial Number |
| Fuel, Lubricant and Coolant Specifications | 20-25 | Diesel Fuel Specifications, Engine Oil Specifications, Break-In Oil, Hydrostatic Transmission and Hydraulic Oil, Alternative Lubricants, Chassis and Anti-Corrosion Grease, Lubricant Storage |
| Diesel Engine | 26-87 | General Engine Specifications, Cooling System Operation, Fuel System Operation, Lubrication System Operation, Cylinder Compression Test, Engine Repair |
| Electrical | 88-229 | Electrical Component Location, Power Circuit Operation, Start Circuit Operation, Charging Circuit Operation, PTO Circuit Operation, Wiring Harness Schematics |
| Power Train - Hydrostatic | 230-285 | Hydrostatic Transaxle Components, Traction Drive Belt System, Pedal Control System, Transaxle Removal and Installation, Transaxle Disassembly and Inspection |
| Steering | 286-307 | Steering System Components, Steering Valve Operation, Tilt Steering Operation, Steering System Leakage Test, Steering Cylinder Repair |
| Brakes | 308-321 | External Brake Linkage, Internal Brake Linkage Operation, Brake Linkage Check and Adjustment, Brake Assembly Repair |
| Hydraulics and Attachments | 322-403 | Hydraulic Lift System Operation, Mower Deck Lift Linkage, 38-Inch Mower Deck Repair, 44-Inch Mower Deck Repair, 48-Inch Mower Deck Repair, 54-Inch Mower Deck Repair |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| Battery Cold Cranking amps | 500 amps | p. 4 |
| Battery Reserve Capacity | 90 minutes | p. 4 |
| Engine Oil Capacity (With Filter) | 2.27 L | p. 11 |
| Engine Oil Capacity (Without Filter) | 2.08 L | p. 11 |
| Transmission Oil Capacity | 4.3 L | p. 12 |
| Engine Mounting Plate Cap Screws | 36 - 43 N•m (313 - 381 lb-in.) | p. 34 |
| Flywheel Cap Screws (Oil Dipped) | 89 - 93 N•m (65 - 68 lb-ft.) | p. 34 |
| Glow Plug Resistance | 1.3—1.7 ohms | p. 97 |
| 38-Inch Mower Deck Cutting Edge Width | 0.40 mm (0.016 in.) | p. 340 |
| 44-Inch Mower Deck Cutting Edge Width | 0.40 mm (0.016 in.) | p. 340 |
| Spindle mounting nuts torque (38-inch mower) | 26 N•m (230 lb-in.) | p. 354 |
| Spindle lock nut torque (38-inch mower) | 140 N•m (103 lb-ft) | p. 354 |
John Deere 355D Common Problems This Manual Covers
John Deere 355D diesel cranks slow and won't start after winter storage, glow plug light stays off
Test battery voltage first; anything below 12.4 volts, charge it or load-test against the 500 cold cranking amp rating on page 12. Clean and tighten both terminals. Then check glow plug resistance, 1.3 to 1.7 ohms per the spec on page 97, before working the cranking checks starting.
Manual Section: Diesel Engine TroubleshootingEngine starts but stalls when load increases, runs rough and hunts at low idle
Replace the fuel filter before chasing anything else; a half-clogged element leans the engine out under load. Bleed the fuel system, then verify slow idle sits at 1000 plus or minus 50 rpm, spec on page 31. Run the fuel and air intake checks starting, and test the seat interlock switch for intermittent cutout.
Manual Section: Diesel Engine Troubleshooting p. 31Hydrostatic transaxle sluggish in forward and reverse, whines under load, loses drive on hills
Check transaxle oil level cold before condemning the pump; low fluid pulls air into the circuit and kills drive. Drain and refill with 4.3 L of Low Viscosity Hy-Gard, capacity spec on page 232, and replace the filter. Inspect the traction drive belt for glazing and check pedal linkage in the Power Train section starting on page 230.
Manual Section: Power Train - Hydrostatic p. 232Mower deck vibrates badly at full throttle and leaves uneven strips of uncut grass
Sharpen or replace the blades first, then measure the tips: outside tip-to-tip height difference over 3 mm (0.125 in.) means a bent blade or spindle, spec on page 348. Level the deck to a 3 to 6 mm front-to-rear rake per page 349, then spin each spindle by hand and feel for bearing roughness.
Manual Section: Mower Deck Troubleshooting p. 348Steering feels heavy and slow to respond, front wheels shimmy at transport speed
Grease every steering pivot and spindle fitting first; dry bushings cause most heavy steering complaints. Check tire pressure, then inspect tie rod ends and drag link for slop. If the wheel wobbles on the shaft, retorque the steering wheel nut to 38 N•m, spec on page 287, and run the leakage test in the Steering section starting on page 286.
Manual Section: Steering Troubleshooting p. 287Frequently Asked Questions
What are the torque specifications for the John Deere 355D wheel bolts?
The rear wheel cap screw torque for the John Deere 355D is 88 N•m (65 lb-ft). p. 387
What are the replacement specifications for the battery?
The battery for the John Deere 355D is a BCI Group 51, 12-volt battery with a cold cranking amp rating of 500 amps at -17.8°C (0°F). p. 12
What is the engine oil capacity for the John Deere 355D?
The engine oil capacity for the John Deere 355D is 2.27 L (2.4 U.S. qt) when changing the filter, and 2.08 L (2.2 U.S. qt) without changing the filter. p. 11
What is the correct valve clearance for the John Deere 355D diesel engine?
The valve clearance for both intake and exhaust valves on the John Deere 355D diesel engine is 0.1 ± 0.05 mm (0.004 ± 0.002 in.) when cold. p. 31
What is the torque specification for the cylinder head cap screws?
The cylinder head cap screws for the John Deere 355D should be tightened to 48 - 51 N•m (35 - 37 lb-ft) while oil dipped. p. 34
What do I get after purchasing this John Deere 355D manual?
This is a 403-page searchable PDF ready for immediate download. Works on any device, so pull it up on your phone while you're under the hood. No shipping, no waiting.
Are there any print restrictions on this John Deere 355D manual?
Yes. The PDF is DRM-free, so printing works from any reader and any printer.
