Part of the John Deere Repair Manuals.
This is the factory repair manual for the John Deere 6405 and 6605 tractors. Both run the same block family: a 4.5 L four cylinder turbo diesel making 77 kW (105 hp) in the 6405, and a 6.8 L six making 84 kW (114 hp) in the 6605. Inside you get engine removal and installation, the fuel, air intake, cooling and exhaust systems, wiring harnesses and the charging and starting circuits, SyncroPlus and Power Reverser transmissions with the creeper option, front wheel drive clutch, final drives, hydrostatic steering, wet disk brakes, the hydraulic pump, rockshaft and selective control valves, plus cab work down to the air conditioning. These are mechanical era tractors, so everything here is printed procedure, specs, and torque values you can work from with hand tools.
What's Inside This John Deere 6405, 6605 Repair Manual
| System | Pages | Key Topics |
|---|---|---|
| Safety | 6-24 | Safety Measures, Machine Runaway Prevention, Fire Hazards, Battery Safety, High-Pressure Fluids, ROPS Maintenance |
| General Information | 25-70 | Specifications, Tune-Up Procedures, Predelivery Inspection, Torque Values, Lubricant Specifications, Product Identification |
| Engine | 71-126 | Engine Removal and Installation, Fuel System, Air Intake, Cooling System, Exhaust System, Cold Weather Starting Aids |
| Fuel, Air Intake, Cooling and Exhaust Systems | 127-170 | Fuel Tank, Fuel Filters, Bleeding the Fuel System, Injection Pump, Injectors, Air Cleaner, Radiator, Exhaust |
| Electrical System | 171-317 | Connectors, Wiring Harnesses, Charging Circuit, Starting Circuit, Fuses and Relays, Monitoring Systems |
| SyncroPlus Transmission | 318-483 | Transmission Removal and Installation, Clutch, Shift Linkage, Creeper, Pressure Tests, Gears and Shafts |
| Power Reverser Transmission | 484-631 | Power Reverser Clutch Pack, Control Valve, Pressure Tests, Reverser Housing, Gears and Shafts |
| Drive Systems | 632-839 | U-Jointed Shafts, Front Wheel Drive Clutch, Differential, Hydraulic Pump Drive, Final Drives, PTO Options |
| Steering and Brakes | 840-933 | Hydrostatic Steering, Steering Cylinders, Brake Valve, Rear Brakes |
| Hydraulic System | 934-1073 | Hydraulic Pump, Valves, Rockshaft, Three-Point Hitch, Selective Control Valves, Independent Control Valve |
| Miscellaneous | 1074-1156 | Main Frame, Front Axle Supports, Ballast and Weights, Tyres and Wheels, Sheet Metal |
| Operator's Cab and Station | 1157-1289 | Cab Removal, Controls and Instruments, Electronic Hitch Control, Air-Conditioning, Heating, Seats |
| Special Tools (Dealer-Fabricated) | 1290-1298 | Dealer-Fabricated Tools, Tool Drawings and Dimensions, Application Notes |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| Engine power at rated engine speed (with viscous fan drive), according to ECE-R24 | 77 kW (105 hp) (6405); 84 kW (114 hp) (6605) | p. 27 |
| Max. PTO power at rated PTO speed (factory measured, with 1000 rpm at PTO) | 69 KW (94 hp) (6405); 74 kW (101 hp) (6605) | p. 27 |
| Number of cylinders | 4 (6405); 6 (6605) | p. 27 |
| Bore | 106.5 mm (4.19 in.) | p. 27 |
| Stroke | 127.0 mm (5.00 in.) | p. 27 |
| Displacement | 4525 cm³ (276 cu.in.) (6405); 6790 cm³ (414 cu.in.) (6605) | p. 27 |
| Firing order | 1-3-4-2 (4-cylinder tractors); 1-5-3-6-2-4 (6-cylinder tractors) | p. 27 |
| Valve clearance (engine cold) - Intake valves | 0.31 mm to 0.38 mm (0.012 in. to 0.015 in.) | p. 27 |
| Valve clearance (engine cold) - Exhaust valves | 0.41 mm to 0.48 mm (0.016 in. to 0.19 in.) | p. 27 |
| Rated engine speed | 2300 rpm | p. 27 |
| Max. torque | 432 N·m (319 lb-ft) (6405 at 1500 rpm); 487 N·m (359 lb-ft) (6605 at 1300 rpm) | p. 27 |
| Power Reverser Transmission Type | synchronized transmission | p. 28 |
| Power Reverser Transmission Range shifting | mechanically, synchronized | p. 28 |
| Power Reverser Transmission Shifting of the 4 gears | mechanically, synchronized | p. 28 |
| Power Reverser Transmission Shifting of the reverse drive lever | mechanical-hydraulic, under load, without operating clutch | p. 28 |
| Power Reverser Transmission 30 km/h (18.5 mph) transmission | 4 ranges | p. 28 |
| HydraVantage Hydraulic System pressure - min. (stand-by) | 1200-1500 kPa (12-15 bar; 174-220 psi) | p. 29 |
| HydraVantage Hydraulic System pressure - max. | 20000 kPa (200 bar; 2900 psi) (tractors up to serial number XXXXXX); 17500 kPa (175 bar; 2540 psi) (tractors from serial number XXXXXX) | p. 29 |
| Fuel tank capacity | 116 L (30.6 U.S. gal.) (6405); 165 L (43.6 U.S. gal.) (6405* and 6605); 207 L (54.6 U.S. gal.)* (6605) | p. 31 |
| Cooling system 6405 - coolant change, tractors with cab | 13.5 L (3.6 U.S. gal.) (6405) | p. 31 |
John Deere 6405, 6605 Common Problems This Manual Covers
Engine hard to start, stalls, or will not fire at all
Start at the Tune-Up group on page 63. If water or sediment has settled in the filter, loosen the drain screw and the bleed screw, retighten both as soon as the deposits have drained, and if there was water in the filter also slacken the drain screw under the fuel tank by one turn, retightening it to 12 N·m (9 lb-ft). Then bleed the air from the fuel system: the manual states the fuel system must be bled whenever it has been run dry. Only after that chase injectors or the injection pump.
Manual Section: General Information, Tune-Up p. 63Weak, slow or noisy hydraulics, implements that barely lift
Check the pressure setting before condemning the pump. Page 1049 states the selective control valves are factory adjusted to 18000 kPa (180 bar; 2610 psi), and page 1050 adds that one full turn of the adjustment changes the pressure by approximately 4600 kPa (46 bar; 670 psi), so a small mis-adjustment moves the setting a long way. Verify oil level and filter condition first, then measure against that figure rather than guessing from how the implement behaves.
Manual Section: Hydraulic System, Selective Control Valves p. 1049Rear PTO will not engage or drops out under load
The rear PTO clutch is a serviceable pack: page 770 walks through repairing it, taking out the cover cap screws, lifting the hub and disks out of the clutch drum and compressing the springs with special tool JDT24A to remove the snap ring. The manual warns to use a 50 x 12 mm (2 x 0.5 in.) washer with the tool or the bearing cone may be damaged. Inspect the disks for wear before assuming an electrical or hydraulic fault.
Manual Section: Drive Systems, Rear PTO p. 770Spongy pedal, weak braking, or brakes that pull to one side
Wet disk rear brakes fade when fluid runs low or air gets into the circuit. The Steering and Brakes section covers bleeding the system, brake valve repair and rear brake disassembly, so you can decide between a reseal and replacing worn disks.
Manual Section: Steering and Brakes p. 885Frequently Asked Questions
My 6405 will not move and the PTO does not work. Will this manual actually help me chase that down?
Yes, and that exact pairing is worth tracing methodically because the transmission clutch and PTO both run on hydraulically controlled wet disk clutches. The manual gives you the Transmission, Drive Systems and Hydraulic System sections to check pressure supply and clutch operation, and the Electrical System section to test the PTO relay, solenoid and wiring before you split anything. p. 770
The tractor is hard to start or stalls under load. Does the manual cover the fuel system properly?
Section 30 covers the whole chain: fuel filters, bleeding air out of the lines, the distributor type injection pump, injectors, the dry type air cleaner with its safety element, and the cold weather starting aids. Nine times out of ten a hard start on these engines is a clogged filter or air on the suction side, and the procedures here let you rule those out cheap before touching the pump. p. 63
Are the torque values and tune up specs in here, or do I still need to hunt them down?
They are in the General Information section along with tune up procedures and lubricant specs. Engine specs are printed too, for example cold valve clearance of 0.31 to 0.38 mm on the intakes, rated speed of 2300 rpm, and the correct engine speeds for 540 and 1000 rpm PTO work. p. 27
Which transmissions does it cover? Mine has the Power Reverser.
Both factory options are covered in full: the SyncroPlus synchronized transmission and the Power Reverser, which shifts direction under load without touching the clutch pedal. The Transmission section also covers the shift controls, the range transmission and the non synchronized creeper reduction that drops ground speed about 90 percent in ranges A, B and C. p. 489
Do I need a laptop or diagnostic tool to use this manual?
No. The 6405 and 6605 are mechanical tractors from before onboard diagnostics, so there are no fault codes to read and nothing to plug into. Every repair in this book is done with hand tools, a multimeter for the electrical circuits, and pressure gauges for the hydraulics, following printed step by step procedures.
What is the torque for the rear wheel retaining cap screws?
On tractors with a flanged rear axle the wheel retaining cap screws are tightened to 500 N\u00b7m (370 lb-ft). The value is printed on page 489. p. 489
