This is the factory repair manual for the John Deere 7425, 7525, 6140J, 6155J, and 6155JH tractors built from 2007 to 2016, the Mexico-market row-crop machines running the 6068 PowerTech diesel and 16F/16R PowrQuad. Inside you get complete teardown and rebuild procedures: cylinder head and crankshaft work, PermaClutch II service, PowrQuad clutch packs, MFWD front axle, wet-disc brakes, hydrostatic steering, and the closed-center hydraulic system with its axial piston pump and SCV stack. Specifications, capacities, torque values, and dealer special tools are all here. Note this is the repair manual; wiring diagnostics and trouble codes live in the companion diagnostic manual TM605919. Instant PDF download, printable, searchable.
What's Inside This John Deere 7425, 7525, 6140J, 6155J, 6155JH Repair Manual
| System | Pages | Key Topics |
|---|---|---|
| Safety | 7-30 | Safety Precautions, Decals, And Service Rules |
| General Information | 31-86 | Specifications, fuel/lubricant Capacities, Torque Values, And Serial Numbers |
| Engine | 87-112 | 6068 PowerTech Engine Repair - Cylinder Head, Block, Pistons, Crankshaft, Timing |
| Fuel, Intake, Cooling and Exhaust | 113-163 | Fuel Injection, Air Intake, Turbocharger, Cooling System, Radiator |
| Electrical System | 164-319 | Charging, Starting, Lighting, Instrument Cluster, And Circuit Diagrams |
| PowrQuad Transmission | 320-469 | 16F/16R PowrQuad Transmission, Clutch Pack, And Controls |
| Drive Systems | 470-696 | MFWD Front Axle, Differential, Final Drives, And PTO |
| Steering and Brakes | 697-771 | Hydrostatic Steering, Brake Valves, And Wet-Disc Brakes |
| Hydraulic System | 772-867 | Hydraulic Pump, Rockshaft, SCV Valves, And pressure/flow Controls |
| Miscellaneous | 868-1071 | Hitch, Drawbar, Ballast, And Attachments |
| Operator's Cab | 1072-1160 | Cab Frame, HVAC, Glass, And Interior Trim |
| Deluxe Seat | 1161-1171 | Air-Suspension Seat Service |
| Special Tools | 1172-1197 | Dealer-Fabricated Service Tools |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| 6140J | ||
| Engine Power (at the PTO) | 92 kW (123 hp) | p. 32 |
| Flywheel Power | 103 kW (138 hp) | p. 32 |
| 6155J and 6155JH | ||
| Engine Power (at the PTO) | 100.6 kW (135 hp) | p. 32 |
| Flywheel Power | 115.5 kW (155 hp) | p. 32 |
| All models | ||
| Bore | 106.5 mm (4.19 in.) | p. 32 |
| Stroke | 127.0 mm (5.0 in.) | p. 32 |
| Compression Ratio | 16.9:1 | p. 32 |
| Intake Valve Clearance | 0.35 mm (0.014 in.) | p. 32 |
| Exhaust Valve Clearance | 0.45 mm (0.018 in.) | p. 32 |
| PTO Operating Speed | Independent | p. 32 |
| Rear PTO (Reversible) - 540/1000 rpm | 1995 rpm | p. 32 |
| PowrQuad Transmission Type | Planetary gears, hydraulically operated | p. 32 |
| Clutch Type | Hydraulically operated PermaClutch II | p. 32 |
| Hydraulic System Type | Closed center, flow and pressure compensated | p. 33 |
| Hydraulic System Pump Type | Axial piston and gear-type pump | p. 33 |
| Hydraulic System Pressure (min) | 2800 to 3300 kPa (28 to 33 bar; 406 to 479 psi) | p. 33 |
| Hydraulic System Pressure (max) | 19512 to 20477 kPa (195 to 204 bar; 2830 to 2970 psi) | p. 33 |
| Steering System Type | Hydrostatic | p. 33 |
| Lifting Capacity - Cat. 3N2 | 3805 kg (8390 lb) 610 mm behind the three-point hitch | p. 33 |
| Cooling System Capacity | 20 L (5.28 U.S.gal.) | p. 38 |
| Engine Crankcase w/Filter Capacity | 19.5 L (5.2 US.gal.) | p. 38 |
| Transmission/hydraulic - PowrQuad transmission capacity | 77 L (20.3 US.gal.) | p. 38 |
| Transmission/hydraulic - extra with creeper transmission capacity | 1 L (0.3 US. gal.) | p. 38 |
| Transmission/hydraulic - extra with front-wheel drive capacity | 3 L (0.8 US. gal.) | p. 38 |
| PTO Operating Speed - 540 rpm PTO (Reversible or Shiftable) | 2143 rpm | p. 39 |
| PTO Operating Speed - 1000 rpm PTO | 2208 rpm | p. 39 |
| Hydraulic System with Axial Piston Pump - System Pressure - Min. (Standby) | 3000 kPa (30 bar; 435 psi) | p. 39 |
| Hydraulic System with Axial Piston Pump - System Pressure - Max. | 20000 kPa (200 bar; 2900 psi) | p. 39 |
| Hydraulic System with Gear Pump - System Pressure - Min. (Standby) | 1200-1500 kPa (12-15 bar; 174-220 psi) | p. 40 |
| Hydraulic System with Gear Pump - System Pressure - Max. | 20000 (200 bar; 2900 psi) | p. 40 |
| Diesel Engine Coolant - Freeze protection (50% ethylene glycol) | -37°C (-34°F) | p. 53 |
| Diesel Engine Coolant - Freeze protection (50% propylene glycol) | -33°C (-27°F) | p. 53 |
| 2WD models | ||
| Turning Radius - 2WD (With 10.00-16 Front Tires) - Without Applying Brakes | 4280 mm (168.5 in.) | p. 34 |
| MFWD models | ||
| Turning Radius - MFWD (With 14.9-28 and 14.9-30 front tires and 1720 mm [68 in.] track) - Disengaged Without Applying Brakes | 4780 mm (188 in.) | p. 34 |
| 6140J Tractor | ||
| Max. Permissible Front Axle Load - Axle without Brake | 4100 kg (9035 lb) | p. 36 |
| Max. Permissible Front Axle Load - Axle with Brake | 4400 kg (9695 lb) | p. 36 |
| Fuel Tank Capacity | 207 L (54.7 US.gal.) | p. 38 |
| 6155J and 6155JH Tractors | ||
| Max. Permissible Front Axle Load - Axle without Brake | 4400 kg (9695 lb) | p. 36 |
| Max. Permissible Front Axle Load - Axle with Brake | 4700 kg (10355 lb) | p. 36 |
| Fuel Tank Capacity | 250 L (66.0 US.gal.) | p. 38 |
