This 429-page John Deere GT242, GT262, GT275 Technical Manual (OEM #TM1582) puts the complete factory service data for these Lawn and Garden Tractors in your hands. Inside: wiring harness diagrams and pinouts for the Electrical section, hydrostatic power train schematics, and a full troubleshooting section covering engine, gear power train, brakes, and mower deck attachments (38, 44, and 48-inch decks included). You get theory of operation, tests and adjustments, and repair procedures for every system, plus torque tables for both standard and metric fasteners. Torque the blade cap screw to 68 N-m (50 lb-ft) and the spark plug to 20 N-m (177 lb-in) exactly like Deere specifies, not a forum estimate. Your mower deck problems, brake linkage issues, and electrical faults all trace back to a spec in here. Bookmarked by section and searchable by keyword, so you can jump straight to the fix from your phone or tablet in the shop.
What's Inside This John Deere GT242, GT262 & GT275 Manual
| System | Pages | Key Topics |
|---|---|---|
| Introduction | 3 | General Diagnostic Information, Specifications, Theory of Operation, Diagnostics, Tests & Adjustments, Repair |
| Safety | 4-8 | Recognize Safety Information, Handle Fluids Safely, Use Care in Handling and Servicing Batteries, Use Safe Service Procedures, Service Tires Safely, Handle Chemical Products Safely |
| Specifications & Information | 9-30 | General Vehicle Specifications, Torque Values, Gasoline Specifications, Engine Oil Specifications, Hydrostatic Transmission and Hydraulic Oil, Serial Number Location |
| Engine | 31-108 | Specifications, Component Location, Theory of Operation, Troubleshooting, Tests and Adjustments, Repair |
| Electrical | 109-202 | Specifications, Theory and Diagnostic Information, Component Location, Electrical Wiring Harnesses, Circuit Operation and Diagnosis, Tests and Adjustments |
| Gear Power Train | 203-252 | Gear Transaxle, Drive Belts, Clutch, Shafts, Component Location, Diagnosis, Tests |
| Hydrostatic Power Train | 253-320 | Hydrostatic Transaxle, Charge Pump, Control Valve, Drive Belts, Component Location, Diagnosis, Tests |
| Steering | 321-328 | Component Location and Operation, Troubleshooting, Diagnosis, Adjustments, Repair |
| Brakes | 329-380 | Adjustment Specifications, External Brake Linkage Operation, Internal Brake Linkage Operation, Brake Components, Brake Linkage Check and Adjustment, Brake Pedal and Linkage |
| Attachments | 381-414 | Adjustment Specifications, 38-Inch Mower Deck Components, 44-Inch Mower Deck Components, 48-Inch Mower Deck Components, Mower Drive Checks, Spindles |
| Miscellaneous | 415-424 | Torque Specifications, Lift Assist and Depth Stop Components and Operation, Lift Assist Checks, Front Axle, Spindle Shafts, Front Wheels |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| All Models | ||
| Fuel Filter | Replaceable, In-Line | p. 11 |
| Air Cleaner | Dual Stage Paper Air Filter and Foam Precleaner | p. 10 |
| Blade Cap Screw Torque | 68 N•m (55 lb-ft) | p. 17 |
| Spark Plug Torque | 20 N•m (177 lb-in.) | p. 15 |
| Spark Plug Gap | 0.76 mm (0.030 in.) | p. 34 |
| Belt Tension (Measured at clutch spring) | 31–35 mm (1.2–1.3 in.) | p. 204 |
| Gear Shift Lever Neutral Adjustment | 5-30 | p. 203 |
| Drive belt (transmission) tension | 31–35 mm (1.2–1.3 in.) | p. 222 |
| Gear backlash | 0.2–0.35 mm (0.008–0.014 in.) | p. 222 |
| GT242 | ||
| Electric PTO Cap Screw Torque | 75 N•m (55 lb-ft) | p. 16 |
| Engine Oil Capacity (with filter) | 1.5 L (3.2 pt.) | p. 10 |
| GT262, GT275 | ||
| Engine Oil Capacity (with filter) | 1.8 L (3.8 pt.) | p. 10 |
John Deere GT242, GT262 & GT275 Common Problems This Manual Covers
John Deere GT242 gear transmission jumps out of gear or won't engage while mowing
Check the clutch actuating spring free length on page 204; it must measure 31 to 35 mm (1.2 to 1.3 in.), replace it if compressed shorter. Inspect the shift linkage for wear at the detent and lubricate the pivot points. Verify gear backlash does not exceed 0.35 mm (0.014 in.) per page 222; excessive play means shim adjustment or gear replacement.
Manual Section: Gear Power Train p. 203Engine stalls under load or refuses to start on the first few pulls
Pull the spark plug and check the gap against the 0.76 mm (0.030 in.) specification before reinstalling, then torque it to 20 N•m (177 lb-in.). Test cylinder compression; minimum acceptable is 483 kPa (71 psi), and low readings point to worn rings or valves. Work through the troubleshooting procedures, then inspect the in-line fuel filter for debris.
Manual Section: EngineMower deck won't engage the PTO clutch or cuts unevenly across the yard
Inspect the electric PTO clutch air gap and reseat the cap screw; torque to 75 N•m (55 lb-ft) on GT242 and GT262, or 56 N•m (45 lb-ft) on GT275, per the specification on page 16. Check drive belt tension, it should deflect 31 to 35 mm (1.2 to 1.3 in.) under load. Replace a glazed or cracked belt.
Manual Section: Attachments p. 16No lights, no start, and intermittent electrical failures after the machine sits overnight
Check ignition switch continuity and battery voltage at rest; a fully charged battery should read at or above 12.6V. Trace the wiring harness for corrosion at the connectors near the frame rail, common on tractors this age. Reference the electrical wiring diagram to isolate the faulty circuit segment, then clean and dielectric-grease every ground connection.
Manual Section: ElectricalHard to shift smoothly into gear when the engine and transmission are still cold
Check the gear shift lever neutral adjustment per the specification on page 203; linkage out of adjustment causes binding as temperatures drop. Verify the shift detent spring has not fatigued and lubricate the shift rail with the specified gear lubricant. Inspect for gear backlash exceeding 0.35 mm (0.014 in.) as listed on page 222, which points to internal wear.
Manual Section: Gear Power Train p. 203Tractor won't move forward or reverse though the engine runs fine and PTO engages
Check hydrostatic transmission oil level; capacity is 4.3 L (4.7 qts) per the specification on page 254, and verify the oil is not aerated or contaminated. Inspect drive belt condition and tension, and confirm the free wheel valve is fully closed for operation, not left open from towing. Review the hydraulic schematic to trace pressure loss in the charge circuit.
Manual Section: Hydrostatic Power Train p. 253Frequently Asked Questions
What are the torque specs for the blade bolt on John Deere GT262?
For the 44-Inch Rear Discharge Mower Deck and 48-Inch Mower Deck, the blade cap screw torque is 68 N•m (50 lb-ft). This specification is crucial for proper blade operation and safety. p. 17
What is the torque specification for the engine mounting bolts on GT262?
The engine mounting cap screw torque for the GT262 is specified as 16.7—22.6 N•m (148.0—200.0 lb-in.). This ensures the engine is securely fastened to the tractor frame. p. 15
What is the recommended engine oil capacity for the John Deere GT242 with a filter?
The engine oil capacity for the John Deere GT242, when including the filter, is 1.5 L (3.2 pt.). This information is found in the general vehicle specifications. p. 10
What is the minimum compression pressure for the engine in GT242, GT262, and GT275 tractors?
The minimum cylinder compression pressure for the engines in GT242, GT262, and GT275 tractors is 483 kPa (71 psi). This value is important for diagnosing engine health. p. 34
What format is this John Deere GT242, GT262, GT275 manual in?
Instant PDF download. You get the full 429-page searchable Technical Manual immediately after payment. Open it on your laptop, tablet, or phone right in the shop.
Can I print this John Deere GT242, GT262, GT275 manual?
No restrictions at all. Print individual pages, full chapters, or the entire manual. The PDF is completely unlocked.
Are there hydraulic schematics in this John Deere GT242, GT262, GT275 manual?
Yes, this John Deere GT242, GT262, GT275 Technical Manual includes a hydraulic system diagram.
