Getting ready to put your tractor to work? This 142-page JCB Fastrac 155 Operator Manual PDF (OEM #9801/1331) details daily operation, maintenance schedules, and cab controls for the entire FASTRAC 125, 135, 155, and 185 series. Inside, you get complete dashboard indicator guides, strict daily maintenance checklists, and a full section on fluid capacities to keep your machine running cool. Open to the service schedules to find exact greasing intervals and safety procedures for operating heavy attachments. Verify your ABS warning lamp triggers correctly above 10 km/h, then lock down the rear axle wheel nuts to exactly 600 Nm before hitting the field. Don't let a simple maintenance oversight sideline your equipment. Grab this bookmarked file, pull it up on your tablet right in the cab, and get back to farming.
What's Inside This JCB FASTRAC 125, 135, 155, 185 Operator Manual
| System | Pages | Key Topics |
|---|---|---|
| Preface | 3-6 | Danger, Warning, Caution, Study This Handbook Before Starting the Machine |
| Safety First - Yours and Other People's | 10-12 | Safety Check List, Operating Safety, Maintenance Safety |
| Safety Decals | 13-14 | - |
| Identifying Your Machine | 15-28 | Serial Number Plate |
| Cab Layout and Controls | 29-33 | Introduction, Entering & Leaving the Cab, Doors and Windows |
| Before Starting the Engine | 34-44 | Digital Speedometer, Instrument Panel, Switches, Seat Adjustment, Air Conditioning and Heater Controls, Seat Belts |
| Travelling | 45-52 | Jump-Starting the Engine, Starting the Engine, Preparing for Travel |
| Using the Machine and Site Safety | 53-57 | Stopping and Parking the Machine |
| External Hydraulics | 58-68 | Rear 3 - Point Linkage, Area Cut-Out, Front Hitch Plate, Front 3 - Point Linkage |
| Independent Power Take-Off (PTO) | 69-78 | Drawbars and Hitches, Connecting Trailer Brakes |
| Automatic Trailer Coupling | 79-82 | - |
| Transporting the Machine | 83-92 | Moving a Disabled Machine, Operating in Low Temperatures |
| Maintenance | 93-142 | Service Requirements, Service Schedules, Lubricants - Health and Safety, Fluids, Lubricants Capacities and Specifications, Cleaning the Machine, Greasing |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| All Models | ||
| Wheel nut torque - Wheel centre to rim nuts C | 600 Nm | p. 133 |
| Wheel nut torque - Rear axles with 12 nuts per wheel | 600 Nm | p. 133 |
| Fuse rating - Clutch depressed start circuit | 10 Amps | p. 136 |
| Fuse rating - Selectronic range change solenoids (when fitted) | 10 Amps | p. 136 |
| ABS fault indication threshold (warning lamp remains on) | above 10 km/h (6 mph) | p. 34 |
| Fuel Capacity | 280 Litres (62.9 UK Gal) | p. 97 |
| Hydraulic System Capacity | 75 Litres (16.5 UK Gal) | p. 97 |
| PTO, Speed and Range Gearboxes Capacity | 38 Litres (8.4 UK Gal) | p. 97 |
| Clutch System Capacity | 0.5 Litres (0.11 UK Gal) | p. 97 |
| Battery Electrolyte Level | 6 mm (0.25 in) above plates | p. 138 |
| Perkins Engine | ||
| Engine Oil Capacity | 16.5 Litres (3.6 UK Gal) | p. 97 |
| Cummins Engine | ||
| Engine Oil Capacity | 15 Litres (3.3 UK Gal) | p. 98 |
JCB FASTRAC 125, 135, 155, 185 Common Problems This Manual Covers
JCB FASTRAC 125 transmission range selection fails to engage and diagnostic LED stays illuminated p. 136
Inspect the air switches and magnetic switches at the rear of the cab. Check the Selectronic range change solenoids fuse on page 136 and replace if blown with a 10 Amp fuse. Verify the hydraulic fluid level to ensure the system maintains its 75 Litres (16.5 UK Gal) capacity.
Manual Section: MaintenanceAnti-lock brake system warning lamp remains continuously illuminated on the dashboard while driving p. 34
Test the tractor and monitor the dashboard indicators. Verify if the ABS fault warning lamp stays on at speeds above 10 km/h (6 mph) as noted on page 34. Check the brake fluid level and confirm the front and rear reservoirs hold their 0.75 Litres (0.17 UK Gal) capacity.
Manual Section: OperationEngine cranks very slowly or completely fails to start during cold morning operation p. 138
Inspect the battery terminals for corrosion and clean them thoroughly. Remove the caps and verify the battery electrolyte level is 6 mm (0.25 in) above the plates as shown on page 138. Test the clutch depressed start circuit fuse and replace with a 10 Amp fuse if necessary.
Manual Section: MaintenanceAir brake system takes too long to build pressure and the compressor squeals p. 141
Inspect the air compressor drive belt for glazing or heavy wear. Adjust the compressor belt tension to exactly 10 mm (0.4 in) of slack as directed on page 141. Drain the air system tanks to remove accumulated moisture and check the lines for visible air leaks.
Manual Section: MaintenanceFrequently Asked Questions
What are the torque specs for JCB Fastrac wheel nuts?
The torque specifications for JCB Fastrac wheel nuts are provided in the manual. For rear axles with 12 nuts per wheel, the torque setting is 600 Nm (61.0 kgf m or 440 lbf ft). For all other axles, the torque setting is 500 Nm (51.0 kgf m or 370 lbf ft). It is recommended to check wheel nut torques every ten hours on a new machine until they remain correct, and daily before starting work.
How do you fix JCB FASTRAC 125 transmission range selection fails to engage and diagnostic LED stays illuminated?
Inspect the air switches and magnetic switches at the rear of the cab. Check the Selectronic range change solenoids fuse on page 136 and replace if blown with a 10 Amp fuse. Verify the hydraulic fluid level to ensure the system maintains its 75 Litres (16.5 UK Gal) capacity.
How do you fix anti-lock brake system warning lamp remains continuously illuminated on the dashboard while driving?
Test the tractor and monitor the dashboard indicators. Verify if the ABS fault warning lamp stays on at speeds above 10 km/h (6 mph) as noted on page 34. Check the brake fluid level and confirm the front and rear reservoirs hold their 0.75 Litres (0.17 UK Gal) capacity.
How do you fix engine cranks very slowly or completely fails to start during cold morning operation?
Inspect the battery terminals for corrosion and clean them thoroughly. Remove the caps and verify the battery electrolyte level is 6 mm (0.25 in) above the plates as shown on page 138. Test the clutch depressed start circuit fuse and replace with a 10 Amp fuse if necessary.
How quickly can I access this manual after?
You get a 142-page searchable PDF that downloads instantly after checkout. Open it on your laptop, tablet, or phone, and bring it right to the shop floor.
Are there any print restrictions on this manual?
No restrictions at all. Print individual pages, full chapters, or the entire manual. The PDF is completely unlocked.
Document Quality
This document is a scanned PDF with an OCR text layer, allowing you to search and copy text from its pages. The text is generally crisp and easy to read, although some characters exhibit slight pixelation typical of a scanned original. Diagrams and illustrations are raster images, not vector, but they are clear, and all labels are fully readable. The page condition is good; pages are clean with very few scan artifacts, and there are no noticeable stains, marks, or skewed pages. Be aware that several blank pages are present throughout the document, reflecting the layout of the original physical manual.
